The curved rod A D of radius r has a weight per length of w...

The curved rod $A D$ of radius $r$ has a weight per length of $w .$ If it lies in the horizontal plane, determine the resultant internal loadings acting on the cross section at point $B .$ Hint: The distance from the centroid $C$ of segment $A B$ to point $O$ is $C O=0.9745 r$

Key Concepts

Resultant Internal Forces and Moments

In beam analysis, especially for curved beams, determining the internal response requires calculating the resultant forces and moments that develop at a cross-section due to applied external loads. These resultants include components like axial force, shear force, and bending moment. Each component arises from different aspects of the load distribution and geometry, and together they describe the overall internal state that must be resisted by the beam's material.

Centroid of a Load Distribution

The centroid of a distributed load is the point at which the entire load can be assumed to act when replacing the continuous load distribution with an equivalent concentrated force. In analyses involving non-uniform or curved distributions, the location of the centroid may not coincide with the geometric center. Accurately determining the centroid is essential because it influences the moment arm used in calculating the moment generated by the load, thereby affecting the internal bending moment computed at the section.

Static Equilibrium

This concept involves ensuring that all forces and moments acting on a structure are in balance. In the context of internal load determination, static equilibrium requires that the sum of all external forces (including distributed loads) and moments (torques) about any point, such as a cross-section through the beam, is zero. This principle is fundamental for analyzing both straight and curved beams and forms the basis for calculating the internal loadings that resist these applied forces.

Distributed Load Integration

Distributed loads represent forces that are spread continuously along the length of a member rather than being concentrated at a single point. To evaluate their effect, such loads are typically integrated over the length of the load application. This integration yields an equivalent resultant force and its point of application, which is often determined by the centroid of the load distribution. This process is critical in converting a distributed load into an equivalent concentrated force and moment, simplifying the analysis of internal loadings.
