The diver leaves the platform with an initial upward speed of $2.5 \mathrm{m} / \mathrm{s}$. A stationary camera on the ground is programmed to track the diver throughout the dive by rotating the lens to keep the diver centered in the captured image. Plot $\dot{\theta}$ and $\ddot{\theta}$ as functions of time for the camera over the entire dive and state the values of $\dot{\theta}$ and $\ddot{\theta}$ at the instant the diver enters the water. Treat the diver as a particle which has only vertical motion. Additionally, state the maximum magnitudes of $\dot{\theta}$ and $\ddot{\theta}$ during the dive and the times at which they occur.

Key Concepts

Projectile Motion Kinematics

This concept covers the analysis of motion under the influence of gravity, where an object is projected with an initial velocity and then follows a parabolic path. In this context, the diver’s vertical motion—with an initial upward speed and subsequent acceleration due to gravity—is modeled using kinematic equations. Understanding projectile motion enables us to determine the diver’s position at any given time, which is fundamental for further analysis of the camera’s tracking behavior.

Angular Kinematics

Angular kinematics involves the study of angular displacement, angular velocity, and angular acceleration, analogous to linear kinematics but for rotational motion. In the problem at hand, the camera tracks the diver by continuously adjusting its orientation, meaning the angle between the camera’s line of sight and a reference line changes over time. Analyzing this angular motion—specifically the derivatives of the angle with respect to time—is essential to determine how the camera rotates to keep the diver centered and to identify key points such as the instant the diver enters the water.

Related Rates

Related rates is a calculus technique used to determine the rates at which related quantities change with respect to time. Here, the diver’s vertical position is changing over time, and this position is geometrically linked to the angle the camera must rotate to track the diver. By applying the concept of related rates, one can differentiate the relationship between the diver’s position and the camera’s angle to find expressions for angular velocity and angular acceleration.

Differentiation and the Chain Rule

Differentiation is a fundamental calculus tool used to compute the rate of change of quantities. The chain rule, a specific differentiation method, is particularly important when differentiating composite functions where one variable depends on another which, in turn, depends on time. In the context of this problem, the angle of the camera is a function of the diver’s position, which is itself a function of time. Applying the chain rule allows for the correct computation of the time derivatives (angular velocity and angular acceleration) necessary to analyze the camera’s tracking performance.
