The electric potential of some configuration is given by the...

The electric potential of some configuration is given by the expression $$ V(\mathbf{r})=A \frac{e^{-\lambda r}}{r} $$ where $A$ and $\lambda$ are constants. Find the electric field $\mathbf{E}(\mathbf{r})$, the charge density $\rho(r)$, and the total charge Q. [Answer; $\left.\rho=\epsilon_{0} A\left(4 \pi \delta^{3}(\mathbf{r})-\lambda^{2} e^{-\lambda r} / r\right)\right]$

The electric potential of some configuration is given by the expression
$$
V(\mathbf{r})=A \frac{e^{-\lambda r}}{r}
$$
where $A$ and $\lambda$ are constants. Find the electric field $\mathbf{E}(\mathbf{r})$, the charge density $\rho(r)$, and the total charge Q. [Answer; $\left.\rho=\epsilon_{0} A\left(4 \pi \delta^{3}(\mathbf{r})-\lambda^{2} e^{-\lambda r} / r\right)\right]$

Key Concepts

Total Charge Calculation

The total charge of a distribution is obtained by integrating the charge density over all space. This concept is essential in verifying consistency with Gauss's law and ensuring that contributions from both continuous distributions and point charges (represented by delta functions) are properly included in the overall charge balance.

Dirac Delta Function

The Dirac delta function is a mathematical tool used to represent point sources in a continuous charge distribution. It simplifies the description of highly localized charges, allowing singularities in the potential or field to be correctly accounted for in the formulation of the charge density.

Poisson's Equation

Poisson's equation relates the Laplacian of the electric potential to the charge density via the equation ?²V = -?/??. This equation serves as a cornerstone in electrostatics for determining how charges generate potentials and, conversely, how the potential distribution encodes information about the charge distribution.

Gauss's Law

Gauss’s law is one of Maxwell's equations that connects the divergence of the electric field to the charge density. It states that the total electric flux through a closed surface is proportional to the enclosed charge, providing an integral method to relate field and charge distributions.

Electric Field

The electric field is a vector field that represents the force experienced by a unit positive charge placed in space. It is related to the electric potential by the gradient operation, specifically E = -?V, and indicates both the magnitude and direction of the force acting on charges.

Electric Potential

The electric potential is a scalar function that describes the work done per unit charge in bringing a test charge from infinity to a point in space. It forms the basis for determining other electromagnetic quantities and provides insight into the distribution of charges that create the field.

Gradient Operator

The gradient operator is a vector differential operator that measures the rate and direction of change in a scalar field. In the context of electric potentials, it is used to compute the electric field, especially in systems with spherical symmetry where the use of spherical coordinates simplifies the calculation.
