The energy of adsorption, $E_{\text {ads }}$, can be measured by the technique of temperature programmed desorption (TPD). In a TPD experiment, the temperature of a surface with bound adsorbate is changed according to the equation $$ T=T_{0}+\alpha t $$ where $T_{0}$ is the initial temperature, $\alpha$ is a constant that determines the rate at which the temperature is changed, and $t$ is the time. A mass spectrometer is used to measure the concentration of molecules that desorb from the surface. The analysis of TPD data depends on the kinetic model for desorption. Consider a first-order desorption process $$ \mathrm{M}-\mathrm{S}(\mathrm{s}) \stackrel{k_{\mathrm{d}}}{\Longrightarrow} \mathrm{M}(\mathrm{g})+\mathrm{S}(\mathrm{s}) $$ Write an expression for the rate law for desorption. Use Equation 1 , Equation $29.37$, and your rate law to show that your rate law can be written as $$ \frac{d[\mathrm{M}-\mathrm{S}]}{d T}=-\frac{[\mathrm{M}-\mathrm{S}]}{\alpha}\left(\tau_{0}^{-1} e^{-E_{\mathrm{at}} / R T}\right) $$ With increasing temperature, $d[\mathrm{M}-\mathrm{S}] / d t$ initially increases, then reaches a maximum, after which it decreases. Let $T=T_{\max }$ be the temperature corresponding to the maximum rate of desorption. Use Equation 2 to show that at $T_{\max }$ $$ \frac{E_{\text {ads }}}{R T_{\max }^{2}}=\frac{\tau_{0}^{-1}}{\alpha} e^{-E_{a b} / R T_{\max }} $$

The energy of adsorption, $E_{\text {ads }}$, can be measured by the technique of temperature programmed desorption (TPD). In a TPD experiment, the temperature of a surface with bound adsorbate is changed according to the equation
$$
T=T_{0}+\alpha t
$$
where $T_{0}$ is the initial temperature, $\alpha$ is a constant that determines the rate at which the temperature is changed, and $t$ is the time. A mass spectrometer is used to measure the concentration of molecules that desorb from the surface. The analysis of TPD data depends on the kinetic model for desorption. Consider a first-order desorption process
$$
\mathrm{M}-\mathrm{S}(\mathrm{s}) \stackrel{k_{\mathrm{d}}}{\Longrightarrow} \mathrm{M}(\mathrm{g})+\mathrm{S}(\mathrm{s})
$$
Write an expression for the rate law for desorption. Use Equation 1 , Equation $29.37$, and your rate law to show that your rate law can be written as
$$
\frac{d[\mathrm{M}-\mathrm{S}]}{d T}=-\frac{[\mathrm{M}-\mathrm{S}]}{\alpha}\left(\tau_{0}^{-1} e^{-E_{\mathrm{at}} / R T}\right)
$$
With increasing temperature, $d[\mathrm{M}-\mathrm{S}] / d t$ initially increases, then reaches a maximum, after which it decreases. Let $T=T_{\max }$ be the temperature corresponding to the maximum rate of desorption. Use Equation 2 to show that at $T_{\max }$
$$
\frac{E_{\text {ads }}}{R T_{\max }^{2}}=\frac{\tau_{0}^{-1}}{\alpha} e^{-E_{a b} / R T_{\max }}
$$

Key Concepts

Temperature Programmed Desorption (TPD)

This technique involves gradually increasing the temperature of a material with adsorbed molecules while monitoring the amount of molecules that desorb. TPD is crucial for studying surface interactions because the desorption rate as a function of temperature provides insights into the strength of adsorption and the kinetics of the desorption process.

First-Order Reaction Kinetics

In kinetics, a first?order process is one where the rate depends linearly on the concentration of the species undergoing the reaction. For desorption, this implies that the rate at which molecules leave the surface is directly proportional to the amount of adsorbed species present, allowing simple mathematical treatment and direct extraction of kinetic parameters from experimental data.

Arrhenius Equation

The Arrhenius equation provides a temperature-dependent expression for the rate constant in chemical kinetics. It expresses the rate constant as a product of a pre-exponential factor and an exponential term that includes the activation energy divided by the product of the gas constant and temperature. This relation is fundamental in connecting experimental observations of reaction rates with the underlying energy barrier for the process.

Heating Rate and Temperature Ramp

In TPD experiments the temperature of the system is deliberately increased at a controlled rate, which is defined by the heating rate. This temperature ramp is crucial for converting time-dependent data into temperature-dependent kinetics, thereby linking the dynamics of desorption with temperature through the chain rule and allowing the extraction of activation energies.

Activation Energy in Adsorption/Desorption

The activation energy, or energy of adsorption in the context of desorption, is the energy barrier that must be overcome for an adsorbed molecule to leave the surface. Its determination from TPD data is central to understanding surface reactions, as it quantifies the strength of interaction between the adsorbate and the substrate and plays a vital role in the design of catalytic and surface phenomena.
