The figure shows a circuit consisting of a battery connected to a resistor and a capacitor, which is fully discharged initially, in series with a switch. a) What is the current in the circuit at any time $t$ ? b) Calculate the total energy provided by the battery from $t=0$ to $t=\infty$. c) Calculate the total energy dissipated from the resistor over the same time period. d) Is energy conserved in this circuit?

The figure shows a circuit consisting of a battery connected to a resistor and a capacitor, which is fully discharged initially, in series with a switch.
a) What is the current in the circuit at any time $t$ ?
b) Calculate the total energy provided by the battery from $t=0$ to $t=\infty$.
c) Calculate the total energy dissipated from the resistor over the same time period.
d) Is energy conserved in this circuit?

Key Concepts

RC Circuit Transients

An RC circuit consists of a resistor and a capacitor connected in series with a voltage source. When the circuit is closed, the capacitor begins to charge through the resistor. The time-dependent behavior of the circuit is governed by the time constant RC, which characterizes the rate at which the capacitor charges. This transient analysis is central to understanding how voltages and currents evolve over time in circuits that involve energy storage and dissipation.

Exponential Decay in Current

In an RC charging circuit, the current decreases exponentially over time. The mathematical description of this behavior is given by an exponential decay function, reflecting how the initial surge of current gradually diminishes as the voltage across the capacitor builds up. This property is crucial for predicting current at any time t and for understanding the dynamics of energy delivery and dissipation in the circuit.

Energy Storage in Capacitors

Capacitors store energy in the electric field between their plates as they charge. The energy stored in a capacitor is given by the formula (1/2)CV^2, where C is the capacitance and V is the voltage across the capacitor. This concept highlights that not all energy supplied by the source is stored, as some energy is converted or lost during the charging process.

Resistor Power Dissipation

Resistors convert electrical energy into thermal energy through the process of Joule heating. In an RC circuit, as the capacitor charges, the resistor dissipates energy at a rate dependent on the square of the instantaneous current. Understanding resistor power dissipation is essential for analyzing energy losses and ensuring that energy balance in the circuit is maintained.

Energy Conservation in Electrical Circuits

Energy conservation in electrical circuits dictates that the total energy provided by the battery is equal to the sum of the energy stored in the capacitor and the energy dissipated by the resistor. This principle is fundamental for verifying the correctness of circuit analysis, especially when calculating energy flows and ensuring that all forms of energy conversion are accounted for.
