The figure shows the side view of a door to a storage compartment. As the 40 -kg uniform door is opened, the light rod slides through the collar at $C$ and compresses the spring of stiffness $k .$ With the door closed $(\theta=0),$ a constant force $P=225 \mathrm{N}$ is applied to the end of the door via a cable. If the door has a clockwise angular velocity of 1 rad/s as the position $\theta=60^{\circ}$ is passed, determine $(a)$ the stiffness of the spring and ( $b$ ) the angular velocity of the door as it passes the position $\theta=45^{\circ} .$ Neglect all friction and the mass of the pulleys at $C$ and $D .$ The spring is uncompressed when the door is vertical, and $b=1.25 \mathrm{m}$

Key Concepts

Conservation of Mechanical Energy

This concept involves balancing the total energy in a mechanical system by accounting for the initial and final kinetic and potential energies, along with any work done by external forces. In problems where friction is negligible, energy losses are minimal and energy conservation can be used to analyze how applied forces, stored energies (such as in springs), and kinetic energy changes relate as a system evolves.

Work?Energy Principle in Rotational Motion

Associated with energy conservation, the work?energy principle in rotational systems states that the work done by torques or applied forces over a rotational displacement is equal to the change in the system’s rotational kinetic energy plus any changes in potential energies. This principle is particularly useful when external forces contribute energy to or extract energy from a rotating body.

Moment of Inertia

The moment of inertia quantifies how a body’s mass is distributed relative to a chosen axis of rotation. It is the rotational analogue of mass in linear dynamics and plays a critical role in determining the angular acceleration produced by a given torque, as well as the rotational kinetic energy of the body.

Elastic Potential Energy in Springs

A spring stores energy when it is deformed from its equilibrium position, with the stored (elastic) potential energy calculated using the expression (1/2)k*x², where k is the spring stiffness and x is the displacement. In mechanical systems involving springs, understanding how energy is stored and released is key for energy balance analyses.

Torque and Lever Arm Relationships

Torque is the rotational equivalent of force and is calculated as the product of an applied force and its lever arm (the perpendicular distance from the axis of rotation to the line of action of the force). This concept is essential when determining how applied forces produce rotational motion and do work on a rotating system.

Geometric Relationships in Mechanisms

Mechanical systems often involve components moving along prescribed paths or converting one type of motion to another (for example, linear to rotational motion). Understanding the geometric constraints and relationships in a mechanism, such as how a sliding rod or cable can affect the compression of a spring in a rotating system, is critical in setting up the equations that describe the system’s behavior.
