The fine structure of an atomic spectrum results from the magnetic field "seen" by an orbiting electron. In this question you will make a semiclassical estimate of the $B$ field seen by a $2 p$ electron in hydrogen. The $B$ field at the center of a circular current loop, $i$, of radius $r$ is known to be $B=\mu_{0} i / 2 r$. (a) Treating the electron and proton as classical particles in circular orbits (each as seen by the other), show that the $B$ field seen by the electron is $$ B=\frac{\mu_{0}}{4 \pi} \frac{e L}{m_{\mathrm{e}} r^{3}} $$ where $L$ is the electron's orbital angular momentum (L $=m_{\mathrm{e}} v r$ for a circular orbit). Remember that the current produced by the orbiting proton is $i=e v / 2 \pi r$, where $v$ is the speed of the proton as seen by the electron (or vice versa). (b) For a rough estimate, you can give $L$ and $r$ their values for the $n=2$ orbit of the Bohr model, $L=2 \hbar$ and $r=4 a_{\mathrm{B}}$. Show that this gives $B \approx 0.39 \mathrm{~T}$ and hence that the separation, $2 \mu_{\mathrm{B}} B$, of the two $2 p$ levels is about $4.5 \times 10^{-5} \mathrm{eV}$. It should be clear that this semi-classical calculation is only a rough estimate. You have used the Bohr values for $L$ and $r .$ If, for example, you had used the quantum value $L=\sqrt{2} \hbar$, this would have changed your answer by a factor of $\sqrt{2} .$ There is another very important reason that the argument used here is only roughly correct: The electron's rest frame is noninertial (since it is accelerated) and a careful analysis by the British physicist L. H. Thomas showed that the energy separation calculated here should include an additional factor of $\frac{1}{2}$. That our answer, $4.5 \times 10^{-5} \mathrm{eV}$, is correct to two significant figures is just a lucky accident.

The fine structure of an atomic spectrum results from the magnetic field "seen" by an orbiting electron. In this question you will make a semiclassical estimate of the $B$ field seen by a $2 p$ electron in hydrogen. The $B$ field at the center of a circular current loop, $i$, of radius $r$ is known to be $B=\mu_{0} i / 2 r$.
(a) Treating the electron and proton as classical particles in circular orbits (each as seen by the other), show that the $B$ field seen by the electron is
$$
B=\frac{\mu_{0}}{4 \pi} \frac{e L}{m_{\mathrm{e}} r^{3}}
$$
where $L$ is the electron's orbital angular momentum (L $=m_{\mathrm{e}} v r$ for a circular orbit). Remember that the current produced by the orbiting proton is $i=e v / 2 \pi r$, where $v$ is the speed of the proton as seen by the electron (or vice versa). (b) For a rough estimate, you can give $L$ and $r$ their values for the $n=2$ orbit of the Bohr model, $L=2 \hbar$ and $r=4 a_{\mathrm{B}}$. Show that this gives $B \approx 0.39 \mathrm{~T}$ and hence that the separation, $2 \mu_{\mathrm{B}} B$, of the two $2 p$ levels is about $4.5 \times 10^{-5} \mathrm{eV}$.

It should be clear that this semi-classical calculation is only a rough estimate. You have used the Bohr values for $L$ and $r .$ If, for example, you had used the quantum value $L=\sqrt{2} \hbar$, this would have changed your answer by a factor of $\sqrt{2} .$ There is another very important reason that the argument used here is only roughly correct: The electron's rest frame is noninertial (since it is accelerated) and a careful analysis by the British physicist L. H. Thomas showed that the energy separation calculated here should include an additional factor of $\frac{1}{2}$. That our answer, $4.5 \times 10^{-5} \mathrm{eV}$, is correct to two significant figures is just a lucky accident.

Key Concepts

Thomas Precession Correction

Thomas precession is a relativistic effect arising from the non-inertial, rotating frame of the orbiting electron. It accounts for discrepancies in the predicted magnetic interaction strength, effectively reducing the spin-orbit coupling energy by a factor of one half. This correction is crucial for accurately matching the semiclassical predictions with experimental observations of fine structure splitting.

Angular Momentum Quantization

Angular momentum quantization is the principle that an electron’s angular momentum in an atom can only take on specific, discrete values. This principle, foundational in both the Bohr model and modern quantum mechanics, relates the electron's orbital parameters—like velocity and radius—to its measurable magnetic and energy characteristics.

Spin-Orbit Coupling

Spin-orbit coupling refers to the interaction between an electron’s spin and its orbital motion. In the electron’s rest frame, the orbital motion of the nucleus creates a magnetic field that interacts with the electron’s magnetic moment, leading to a splitting of the atomic energy levels. This phenomenon is one of the primary sources of the fine structure observed in atomic spectra.

Semiclassical Approximation

The semiclassical approximation blends classical physics with quantum concepts by treating electron motion as classical trajectories while imposing quantum constraints like quantized angular momentum. This approach yields estimates of atomic properties, such as magnetic fields and energy level splittings, that capture essential physics despite the complex quantum nature of the system.

Bohr Model

The Bohr model of the atom introduces the idea that electrons occupy discrete orbits with quantized angular momentum. It provides simple relations for the electron's orbital radius and energy that serve as useful approximations when calculating properties like magnetic fields and energy separations in hydrogen-like atoms.

Magnetic Field of a Current Loop

A key concept is that a circulating current produces a magnetic field; specifically, a circular current loop generates a field at its center proportional to the current and inversely proportional to the loop radius. This classical result is applied to atomic systems by modeling the moving charge as a current, thereby allowing an estimate of the magnetic field experienced by an electron.
