The following curve-fit for the drag coefficient of a smooth sphere as a function of Reynolds number has been proposed by Chow [36]:
$$\begin{array}{lcc}
C_{D}=24 / R e & R e \leq 1 \\
C_{D}=24 / R e^{0.646} & 1<R e \leq 400 \\
C_{D}=0.5 & 400<R e \leq 3 \times 10^{5} \\
C_{D}=0.000366 R e^{0.4275} & 3 \times 10^{5}<R e \leq 2 \times 10^{6} \\
C_{D}=0.18 & R e>2 \times 10^{6}
\end{array}$$
Use data from Fig. 9.11 to estimate the magnitude and location of the maximum error between the curve fit and data.

Key Concepts

Drag Coefficient

The drag coefficient is a dimensionless number used in fluid dynamics to quantify the resistance or drag force an object experiences as it moves through a fluid. It relates the drag force to fluid density, velocity, and a characteristic area of the object, allowing for comparison of different shapes and flow conditions.

Reynolds Number

The Reynolds number is a dimensionless parameter that compares inertial forces to viscous forces in a fluid flow. It plays a critical role in determining the flow regime—laminar, transitional, or turbulent—which significantly influences the behavior of drag and other aerodynamic properties.

Curve Fitting

Curve fitting involves constructing a mathematical expression that best approximates the relationship observed in a set of data. In the context of drag coefficient analysis, it is used to develop an empirical model that represents how the drag coefficient changes with different Reynolds numbers over defined ranges.

Error Analysis

Error analysis is the process of quantifying the differences between values predicted by a model and the actual experimental data. This assessment helps identify the magnitude and location of the largest discrepancies, which is crucial for understanding the limitations and accuracy of the proposed model.

Model Validation

Model validation is the procedure of comparing model predictions with real-world experimental or recorded data to determine the model’s reliability and accuracy. It is an essential step in ensuring that the curve-fit accurately reflects the physical phenomena observed in experiments.
