The following data were obtained for the adsorption of N2( g) to a piece of solid graphite at 19

step 1 In order to find the enthalpy of absorption, we have to use this equation. And this equation say

The following data were obtained for the adsorption of...

The following data were obtained for the adsorption of $\mathrm{N}_{2}(\mathrm{~g})$ to a piece of solid graphite at $197 \mathrm{~K}$. The tabulated volumes are the volumes that the adsorbed gas would occupy at $0.00^{\circ} \mathrm{C}$ and one bar \begin{tabular}{c|ccccc} $P /$ bar & $3.54$ & $10.13$ & $\underline{16}: 92$ & $\underline{26.04}$ & $\underline{29}: 94$ \\ \hline$V / 10^{-4} \mathrm{~m}^{3}$ & 328 & 456 & 497 & 527 & 536 \end{tabular} Determine the values of $V_{\mathrm{m}}$ and $b$ using the Langmuir adsorption isotherm. The total mass of the carbon solid is $13.25 \mathrm{~g}$. Determine the fraction of the carbon atoms that are accessible as binding sites if you assume that each surface atom can adsorb one $\mathrm{N}_{2}$ molecule.

The following data were obtained for the adsorption of $\mathrm{N}_{2}(\mathrm{~g})$ to a piece of solid graphite at $197 \mathrm{~K}$. The tabulated volumes are the volumes that the adsorbed gas would occupy at $0.00^{\circ} \mathrm{C}$ and one bar
\begin{tabular}{c|ccccc}
$P /$ bar & $3.54$ & $10.13$ & $\underline{16}: 92$ & $\underline{26.04}$ & $\underline{29}: 94$ \\
\hline$V / 10^{-4} \mathrm{~m}^{3}$ & 328 & 456 & 497 & 527 & 536
\end{tabular}
Determine the values of $V_{\mathrm{m}}$ and $b$ using the Langmuir adsorption isotherm. The total mass of the carbon solid is $13.25 \mathrm{~g}$. Determine the fraction of the carbon atoms that are accessible as binding sites if you assume that each surface atom can adsorb one $\mathrm{N}_{2}$ molecule.

Key Concepts

Conversion of Adsorbed Volume to Moles Using Standard Conditions

In adsorption studies, the experimentally measured volume of adsorbed gas often needs to be converted to moles, typically under standard conditions (0°C and 1 bar). This conversion is essential because it allows the quantitative analysis of the adsorption process using the ideal gas law. Understanding how to relate volume measurements to the number of moles is key when interpreting adsorption data and applying models like the Langmuir isotherm.

Adsorption Equilibrium Constant (b)

The adsorption equilibrium constant, b, reflects the affinity between the adsorbate molecules and the adsorbent surface. It quantifies the strength of the adsorption interaction and appears in the Langmuir equation to balance the adsorption and desorption rates. A higher b value suggests a stronger binding, meaning that adsorption will occur readily even at lower pressures, while a lower b indicates weaker interactions.

Accessible Surface Sites

Calculating the fraction of accessible surface sites involves determining how many surface atoms are available to bind adsorbate molecules relative to the total number of atoms in the material. This concept is important for linking the macroscopic adsorption capacity with the microscopic structure of the adsorbent. It assumes that each accessible surface atom can act as an individual binding site, which provides insights into the efficiency and characteristics of the material's surface.

Langmuir Adsorption Isotherm

The Langmuir adsorption isotherm is a model that describes adsorption processes on a homogeneous surface, assuming that a fixed number of identical sites are available. It is based on the idea of monolayer coverage where each site can adsorb only one molecule and there are no interactions between adsorbed molecules. The isotherm relates the pressure of the adsorbate to the fraction of surface sites occupied and is typically represented by an equation involving the maximum adsorption capacity and an equilibrium constant.

Monolayer Capacity (V?)

Monolayer capacity represents the amount of adsorbate needed to form a single, complete layer of molecules on the surface of the adsorbent. It is a critical parameter in the Langmuir isotherm, indicating the total number of adsorption sites available on the solid surface. Determining V? allows one to understand the storage capacity of a material and is useful for characterizing surface area and adsorption potential.
