The forces on a dancer can be measured directly when a dancer performs a jump on a force plate that measures the force between her feet and the ground. A graph of force versus time throughout a vertical jump performed on a force plate is shown in Fig. $\mathbf{P 4 . 6 0 .}$. What is happening at $0.4 \mathrm{~s}$ ? The dancer is (a) bending her legs so that her body is accelerating downward; (b) pushing her body up with her legs and is almost ready to leave the ground; (c) in the air and at the top of her jump; (d) landing and her feet have just touched the ground.

The forces on a dancer can be measured directly when a dancer performs a jump on a force plate that measures the force between her feet and the ground. A graph of force versus time throughout a vertical jump performed on a force plate is shown in Fig. $\mathbf{P 4 . 6 0 .}$. What is happening at $0.4 \mathrm{~s}$ ? The dancer is (a) bending her legs so that her body is accelerating downward; (b) pushing her body up with her legs and is almost ready to leave the ground; (c) in the air and at the top of her jump;
(d) landing and her feet have just touched the ground.

Key Concepts

Force Plate Measurement

A force plate is a device used to measure the forces exerted on it, particularly the normal force from the ground. It provides a quantitative way to analyze how forces change over time during activities like jumping and landing, which is essential in biomechanics and sports science.

Force vs. Time Graph Interpretation

A force versus time graph displays how the force applied to a system changes over time. By analyzing the different segments and peaks of the curve, one can identify various phases of a dynamic movement, such as the force buildup during take-off, periods of free flight when force drops, and force spikes upon landing.

Phases of a Vertical Jump

A vertical jump typically consists of distinct phases including the preparatory phase (crouching), the push-off phase (rapid force generation), the airborne phase (when the jumper is in free flight and the force plate records minimal or no force), and the landing phase (impact force when contacting the ground). Recognizing these phases helps correlate force measurements with the corresponding movement stages.

Newton's Second Law of Motion

Newton's Second Law states that the net force acting on an object is equal to the mass of the object multiplied by its acceleration (F = ma). This principle is fundamental to understanding how changes in the measured force relate directly to the acceleration or deceleration of the jumper during different phases of a jump.

Impulse-Momentum Theorem

The impulse-momentum theorem explains that the impulse, which is the integral of force over time, results in a change in an object's momentum. In the context of a jump, calculating the area under segments of the force versus time graph helps determine the velocity changes of the jumper, thereby linking force application to motion outcomes.
