The given figure shows an infinite ladder network of...

The given figure shows an infinite ladder network of resistances. The equivalent resistance between points $\mathrm{A}$ and $\mathrm{B}$ is.
(A) Infinite
(B) $3.73 \Omega$
(C) $2.73 \Omega$
(D) $(2 / 3) \Omega$

Key Concepts

Solving Quadratic Equations

The recursive nature of an infinite network’s equivalent resistance often results in a quadratic equation. Solving this quadratic equation is a critical step in finding the equivalent resistance, as it allows for the determination of the value that satisfies the self-similar property of the network.

Self-Similarity in Networks

Self-similarity refers to the property of an infinite network where a part of the network is identical to the whole. This allows one to assume that adding another section of the network does not change the overall equivalent resistance, leading to a recursive equation that can be solved to determine the circuit’s equivalent resistance.

Infinite Resistor Networks

An infinite resistor network is a circuit composed of an unending repetition of basic circuit elements. In such networks, the repeating structure allows for analysis techniques that exploit the fact that the network’s properties are preserved even as additional sections are added, making it possible to define an equivalent resistance for the entire network.

Series and Parallel Resistance Combination

Calculating the equivalent resistance in circuits often requires the use of series and parallel resistor combination rules. In series configurations, the resistances add directly, whereas in parallel configurations, the reciprocal of the equivalent resistance is the sum of the reciprocals of the individual resistances. This concept is fundamental in analyzing more complex networks such as the infinite ladder network.
