The head versus capacity curve for a certain fan may be approximated by the equation $H=30-10^{-7} Q^{2},$ where $H$ is the output static head in inches of water and $Q$ is the air flow rate in $\mathrm{ft}^{3} / \mathrm{min}$. The fan outlet dimensions are $8 \times 16$ in. Determine the air flow rate delivered by the fan into a $200 \mathrm{ft}$ straight length of $8 \times 16$ in. rectangular duct.

Key Concepts

Fan Performance Curve

The fan performance curve describes the relationship between the static head (pressure produced by the fan) and the volumetric air flow rate. It is typically derived from experiments or design calculations, and in this case, the relationship is approximated by the equation H = 30 - 10?? Q². This curve is fundamental in evaluating how a fan will perform under various flow conditions, and it is used as a basis for matching the fan to the system in which it operates.

System (Duct) Pressure Loss

Duct pressure loss, often referred to as the system or duct loss curve, characterizes how the static pressure decreases along the duct due to friction and other resistances. These losses depend on the duct geometry (such as cross-sectional dimensions and length) and the flow characteristics. In system design, determining the pressure drop in the duct ensures that the fan’s output pressure is sufficient to overcome these losses.

Operating Point of a Fan System

The operating point is the intersection between the fan performance curve and the system (duct) pressure loss curve. It represents the steady-state condition where the static head generated by the fan exactly balances the losses in the system, thus determining the actual air flow rate and pressure in operation. Identifying this point is crucial in ensuring that the fan and duct are properly matched for efficient system performance.

Air Flow Rate and Duct Cross?Sectional Area

The cross-sectional area of the duct is key in relating the volumetric flow rate to the air velocity within the duct. Calculating the duct area from its dimensions allows engineers to apply principles of fluid dynamics, such as continuity and energy conservation, to estimate velocity, frictional losses, and overall duct performance. It is an essential step when integrating fan performance with duct system analysis.
