The horizontal beam is assumed to be rigid and supports the distributed load shown. Determine the angle of tilt of the beam after the load is applied. Each support consists of a wooden post having a diameter of 120 mm and an unloaded (original) length of 1.40 m . Take $E_{\mathrm{w}}=12 \mathrm{GPa}$.

Key Concepts

Rigid Body Rotation

This concept involves treating a structural element as non-deformable in itself while allowing for rotation due to movements at its supports. In the context of the problem, even though the beam is assumed to be rigid (i.e. it does not flex), the overall system can still experience a tilt because of differential deformations at the supports, resulting in a rotation or angular displacement of the beam.

Distributed Load

A distributed load is a load applied continuously along the length or surface of an element rather than at discrete points. Understanding how to represent and integrate the effects of a distributed load is critical for analyzing structural responses, since the load's distribution influences the forces and moments that need to be balanced in the structure.

Elastic Modulus and Material Deformation

The modulus of elasticity (in this case for wood) quantifies a material's resistance to elastic deformation under load. It is a fundamental material property used to determine the amount of compression or elongation a material will experience when subjected to a given stress, and is central to calculating the deformations in the wooden posts supporting the beam.

Column Compression

This concept refers to the shortening or compression of vertical supports (columns) under a vertical load. In the problem, the wooden posts hold the beam and experience compressive deformations due to the applied load. Analyzing how these compressions differ helps in determining the differential displacements that contribute to the tilt of the beam.

Equilibrium and Structural Stiffness

Understanding static equilibrium and the concept of stiffness is essential when analyzing structural systems. The distribution of the load, the geometry of the supports, and the material properties all influence how forces are transferred throughout the structure. In this problem, balance of forces and moments, along with the stiffness of the posts, dictate the overall tilt angle of the beam.
