The motor of a table saw is rotating at 3450 rev / min. A...

The motor of a table saw is rotating at 3450 rev $/$ min. A pulley attached to the motor shaft drives a second pulley of half the diameter by means of a V-belt. A circular saw blade of diameter $0.208 \mathrm{~m}$ is mounted on the same rotating shaft as the second pulley. (a) The operator is careless and the blade catches and throws back a small piece of wood. This piece of wood moves with linear speed equal to the tangential speed of the rim of the blade. What is this speed? (b) Calculate the radial acceleration of points on the outer edge of the blade to see why sawdust doesn't stick to its teeth.

Key Concepts

Centripetal (Radial) Acceleration

Centripetal acceleration is the acceleration experienced by any point moving in a circular path and is directed towards the center of rotation. It is determined by the square of the angular velocity times the radius. This concept explains why objects, such as sawdust on a rapidly rotating blade, are forced outward yet still adhere to circular paths, providing insights into the forces acting on rotating systems.

Tangential (Linear) Speed

The tangential speed is the linear speed at any point on the rim of a rotating object, calculated as the product of the radius and the angular velocity. This concept links the rotational motion to the linear motion of points along the circumference, making it useful for determining the speed of objects that interact with the rotating part.

Angular Velocity and Unit Conversion

Angular velocity is a measure of how quickly an object rotates, typically expressed in radians per second. Converting revolutions per minute (rev/min) to radians per second is a common necessity in rotation problems because many formulas, such as those for tangential speed and centripetal acceleration, require angular velocity to be in SI units.

Pulley Ratio and Mechanical Advantage

Pulley systems are used to change the speed and torque between the driving and driven components. The ratio of the diameters or radii of the pulleys directly translates into the ratio of their angular velocities. When a smaller pulley is driven by a larger one, the angular speed increases, allowing for the modification of output speed without directly altering the input rotational speed.
