The New Technology Telescope (NTT) is operated by the European Southern Observatory at Cerro La Silla. This telescope was used as a testbed for evaluating the adaptive optics technology used in the VLT. The NTT has a 3.58 -m primary mirror with a focal ratio of $f / 2.2$ (a) Calculate the focal length of the primary mirror of the New Technology Telescope. (b) What is the value of the plate scale of the NTT? (c) $\epsilon$ Bootes is a double star system whose components are separated by $2.9^{\prime \prime} .$ Calculate the linear separation of the images on the primary mirror focal plane of the NTT.

The New Technology Telescope (NTT) is operated by the European Southern Observatory at Cerro La Silla. This telescope was used as a testbed for evaluating the adaptive optics technology used in the VLT. The NTT has a 3.58 -m primary mirror with a focal ratio of $f / 2.2$
(a) Calculate the focal length of the primary mirror of the New Technology Telescope.
(b) What is the value of the plate scale of the NTT?
(c) $\epsilon$ Bootes is a double star system whose components are separated by $2.9^{\prime \prime} .$ Calculate the linear separation of the images on the primary mirror focal plane of the NTT.

Key Concepts

Focal Ratio

The focal ratio, or f-number, of a telescope is defined as the ratio of its focal length to the diameter of its primary optical element (mirror or lens). It is a critical parameter because it influences the light gathering power, the field of view, and the overall image brightness of the telescope. A lower f-number generally indicates a ‘faster’ system which can yield a brighter image over a wider field.

Focal Length

The focal length is the distance between the telescope’s primary mirror (or lens) and the point where the incoming light converges to form an image. It plays a vital role in determining the magnification of the telescope as well as the scale at which celestial objects are imaged on the detector or focal plane.

Plate Scale

The plate scale of a telescope establishes the conversion between angular measurements in the sky and linear measurements on the telescope's detector or focal plane. Expressed typically in arcseconds per millimeter, it enables astronomers to relate the angular separation of objects (like stars) to their physical separation in the instrument’s focal plane.

Conversion from Angular to Linear Separation

Under the small angle approximation, an angular separation observed in the sky can be converted into a linear separation on the focal plane by multiplying the angle (in radians) by the telescope's focal length. This relationship is fundamental in astrophysical imaging, as it allows observational measurements (in arcseconds) to be translated into physical distances on the detector.
