The Newcomen engine was the first working steam engine with a piston; it was constructed by Thomas Newcomen through incremental improvements between 1705 and 1711 and was ultimately widely used. A large cylinder (e.g. radius 1 metre, height several metres) was closed by a piston attached to one end of a heavy balanced beam. As the beam rocked to and fro, the other end provided work, for example to drive a water pump. The working principle of the Newcomen engine is as follows. A coal fire heats a quantity of water in a boiler. During the down-stroke on the pump, which is the up-stroke on the piston, steam fills the cylinder, but no useful work is done because the steam pressure is roughly $1 \mathrm{~atm}$; the weight of the pump rod provides the force required to lift the piston. At the top of the piston stroke, a valve to the boiler is closed, and another valve to a supply of cold water under pressure is briefly opened. Some cold water sprays into the chamber. Since this water is much colder than the steam, heat flows from the latter to the former, and the steam condenses. The pressure in the chamber therefore drops considerably, 'sucking' the piston downwards-which is to say, the atmospheric pressure above the piston pushes it down. This is why such engines are called 'atmospheric' engines. This is the power stroke. When the piston reaches the bottom, the valve to the boiler is re-opened and the incoming steam pushes the cold water out of the chamber. (i) If the cylinder radius is $1 \mathrm{~m}$, and the working stroke of the piston is $3 \mathrm{~m}$, calculate the mass of steam required to fill the chamber at $100^{\circ} \mathrm{C}, 100 \mathrm{kPa}$. Determine the heat input required to produce this amount of steam from water initially at $15^{\circ} \mathrm{C}$. (ii) Determine the amount of water at $15^{\circ} \mathrm{C}$ that will suffice to lower the pressure to $50 \mathrm{kPa}$. (iii) Find the work output per cycle, and hence the average power output if the machine executes 15 cycles per minute. How does this compare to the heat input in part (i)?

Name: Problem 7, Chapter 11: Thermodynamics: A complete undergraduate course
Uploaded: 2020-07-08T19:00:08-08:00
Duration: 12 min 21 s
Channel: Sanjeev Kumar

    The Newcomen engine was the first working steam engine with a piston; it was constructed by Thomas Newcomen through incremental improvements between 1705 and 1711 and was ultimately widely used. A large cylinder (e.g. radius 1 metre, height several metres) was closed by a piston attached to one end of a heavy balanced beam. As the beam rocked to and fro, the other end provided work, for example to drive a water pump. The working principle of the Newcomen engine is as follows. A coal fire heats a quantity of water in a boiler. During the down-stroke on the pump, which is the up-stroke on the piston, steam fills the cylinder, but no useful work is done because the steam pressure is roughly $1 \mathrm{~atm}$; the weight of the pump rod provides the force required to lift the piston. At the top of the piston stroke, a valve to the boiler is closed, and another valve to a supply of cold water under pressure is briefly opened. Some cold water sprays into the chamber. Since this water is much colder than the steam, heat flows from the latter to the former, and the steam condenses. The pressure in the chamber therefore drops considerably, 'sucking' the piston downwards-which is to say, the atmospheric pressure above the piston pushes it down. This is why such engines are called 'atmospheric' engines. This is the power stroke. When the piston reaches the bottom, the valve to the boiler is re-opened and the incoming steam pushes the cold water out of the chamber.
(i) If the cylinder radius is $1 \mathrm{~m}$, and the working stroke of the piston is $3 \mathrm{~m}$, calculate the mass of steam required to fill the chamber at $100^{\circ} \mathrm{C}, 100 \mathrm{kPa}$. Determine the heat input required to produce this amount of steam from water initially at $15^{\circ} \mathrm{C}$.
(ii) Determine the amount of water at $15^{\circ} \mathrm{C}$ that will suffice to lower the pressure to $50 \mathrm{kPa}$.
(iii) Find the work output per cycle, and hence the average power output if the machine executes 15 cycles per minute. How does this compare to the heat input in part (i)?

Thermodynamics: A complete undergraduate course

Andrew M. Steane 1st Edition

Chapter 11, Problem 7

Instant Answer

Solved by Expert Sanjeev Kumar

07/08/2020

Step 1

- The volume $ V $ of a cylinder is given by the formula $ V = \pi r^2 h $. - Given the radius $ r = 1 \, \text{m} $ and the height (working stroke) $ h = 3 \, \text{m} $, we have: \[ V = \pi (1)^2 (3) = 3\pi \, \text{m}^3 \] Show more…

Show all steps

Thanks for your feedback!

The Newcomen engine was the first working steam engine with a piston; it was constructed by Thomas Newcomen through incremental improvements between 1705 and 1711 and was ultimately widely used. A large cylinder (e.g. radius 1 metre, height several metres) was closed by a piston attached to one end of a heavy balanced beam. As the beam rocked to and fro, the other end provided work, for example to drive a water pump. The working principle of the Newcomen engine is as follows. A coal fire heats a quantity of water in a boiler. During the down-stroke on the pump, which is the up-stroke on the piston, steam fills the cylinder, but no useful work is done because the steam pressure is roughly $1 \mathrm{~atm}$; the weight of the pump rod provides the force required to lift the piston. At the top of the piston stroke, a valve to the boiler is closed, and another valve to a supply of cold water under pressure is briefly opened. Some cold water sprays into the chamber. Since this water is much colder than the steam, heat flows from the latter to the former, and the steam condenses. The pressure in the chamber therefore drops considerably, 'sucking' the piston downwards-which is to say, the atmospheric pressure above the piston pushes it down. This is why such engines are called 'atmospheric' engines. This is the power stroke. When the piston reaches the bottom, the valve to the boiler is re-opened and the incoming steam pushes the cold water out of the chamber. (i) If the cylinder radius is $1 \mathrm{~m}$, and the working stroke of the piston is $3 \mathrm{~m}$, calculate the mass of steam required to fill the chamber at $100^{\circ} \mathrm{C}, 100 \mathrm{kPa}$. Determine the heat input required to produce this amount of steam from water initially at $15^{\circ} \mathrm{C}$. (ii) Determine the amount of water at $15^{\circ} \mathrm{C}$ that will suffice to lower the pressure to $50 \mathrm{kPa}$. (iii) Find the work output per cycle, and hence the average power output if the machine executes 15 cycles per minute. How does this compare to the heat input in part (i)?

Play audio

Feedback

Sanjeev Kumar and 86 other educators are ready to help you.

Ask a new question

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Work Output and Efficiency in Thermodynamic Cycles

This involves calculating the work done per cycle by the engine and comparing it to the heat input. It is a fundamental thermodynamic analysis that assesses the efficiency of energy conversion processes in engines, bridging the gap between theoretical energy inputs and practical mechanical outputs.

Phase Change and Condensation Impact on Pressure

This concept explains how the condensation of steam into water within the cylinder reduces the pressure, leading to a pressure differential that enables the atmospheric pressure to push the piston. Analyzing the thermodynamic implications of phase change is vital for understanding the power stroke in steam engines.

Thermal Energy Calculations (Sensible and Latent Heat)

Understanding how much energy is required to heat water and convert it into steam involves both sensible heat (energy needed to raise the temperature of water) and latent heat (energy needed for the phase change from liquid to vapor). This concept is essential for quantifying the total heat energy input in steam generation processes.

Ideal Gas Law and Thermodynamic States

This concept involves applying the ideal gas law to analyze the state of steam under various conditions of pressure and temperature. It is crucial for determining properties such as mass, volume, and density of steam, which are necessary for calculating both the energy input and the performance of the engine during different phases of its cycle.

Piston-Cylinder Mechanism

The piston-cylinder mechanism is a fundamental component in many heat engines, where a piston moves inside a cylinder to convert pressure into mechanical motion. It involves the understanding of geometry, forces, and motion, which are key to calculating the work output and mechanical performance of the engine.

Atmospheric Steam Engine

This concept covers the basic operating principle of early steam engines where atmospheric pressure is utilized to move a piston. In these engines, steam is used to create a pressure differential, and then its condensation in the cylinder causes a drop in pressure that allows atmospheric pressure to push the piston, converting thermal energy into mechanical work.
