The pan flute is a musical instrument consisting of a number of closed-end tubes of different lengths. When the musician blows over the open ends, each tube plays a different note. The longest pipe is $0.33 \mathrm{m}$ long. What is the frequency of the note it plays?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Standing Waves in Closed Pipes

In a closed-end tube, standing waves are formed when sound waves reflect off the boundaries. The closed end must always be a node (point of no displacement), and the open end becomes an antinode (point of maximum displacement). The lowest frequency mode (fundamental frequency) in such a setup has a wavelength that is four times the length of the tube.

Frequency Calculation of Sound Waves

The frequency of a sound wave is determined by the relationship f = v/?, where f is the frequency, v is the speed of sound, and ? is the wavelength. In the case of a closed-end pipe, the effective wavelength for the fundamental frequency is four times the length of the instrument, so the frequency can be calculated using f = v/(4L).

Speed of Sound in Air

The speed of sound in air, typically around 343 meters per second under ordinary conditions, is essential in connecting the physical dimensions of a musical instrument to the sound it produces. It represents how fast sound energy travels through the medium and is used to determine the frequency when combined with the wavelength.
