The parameters of an n-channel enhancement-mode MOSFET are...

The parameters of an n-channel enhancement-mode MOSFET are $V_{T}=0.40 \mathrm{~V}$, $t_{\text {ox }}=20 \mathrm{~nm}=200 \AA, L=1.0 \mu \mathrm{m}$, and $W=10 \mu \mathrm{m} .$ (a) Assuming a constant mobility of $\mu_{n}=475 \mathrm{~cm}^{2} / \mathrm{V}-\mathrm{s}$, calculate $I_{D}$ for $V_{G S}-V_{T}=2.0 \mathrm{~V}$ when biased at $(i) V_{D S}=0.5 \mathrm{~V},(i i) V_{D S}=1.0 \mathrm{~V},($ iii $) V_{D S}=1.25 \mathrm{~V}$, and $(i v) V_{D S}=2.0 \mathrm{~V}$. (b) Consider the piecewise linear model of the carrier velocity versus $V_{D S}$ shown in Figure $\mathrm{P} 11.13$. Calculate $I_{D}$ for the same voltage values given in part $(a) .$ [See Equation ( $11.17) .]$ ( $c$ ) Determine the $V_{D S}$ (sat) values for parts ( $a$ ) and $(b)$.

The parameters of an n-channel enhancement-mode MOSFET are $V_{T}=0.40 \mathrm{~V}$, $t_{\text {ox }}=20 \mathrm{~nm}=200 \AA, L=1.0 \mu \mathrm{m}$, and $W=10 \mu \mathrm{m} .$ (a) Assuming a constant mobility of $\mu_{n}=475 \mathrm{~cm}^{2} / \mathrm{V}-\mathrm{s}$, calculate $I_{D}$ for $V_{G S}-V_{T}=2.0 \mathrm{~V}$ when biased at $(i) V_{D S}=0.5 \mathrm{~V},(i i) V_{D S}=1.0 \mathrm{~V},($ iii $) V_{D S}=1.25 \mathrm{~V}$, and $(i v) V_{D S}=2.0 \mathrm{~V}$.
(b) Consider the piecewise linear model of the carrier velocity versus $V_{D S}$ shown in Figure $\mathrm{P} 11.13$. Calculate $I_{D}$ for the same voltage values given in part $(a) .$ [See Equation ( $11.17) .]$ ( $c$ ) Determine the $V_{D S}$ (sat) values for parts ( $a$ ) and $(b)$.

Key Concepts

MOSFET Operating Regions

In MOSFET operation, the device behaves differently depending on the applied voltages. For VGS greater than VT, a conductive channel is established. When VDS is low, the device operates in the linear (or triode) region where the drain current increases approximately linearly with VDS. As VDS increases and reaches a critical point (typically VGS - VT), the MOSFET enters the saturation region, where the current becomes nearly independent of VDS. Understanding these regions is essential for designing and analyzing MOSFET circuits.

Drain Current Calculation in MOSFETs

The drain current (ID) in a MOSFET is calculated based on device parameters such as the gate bias (VGS), threshold voltage (VT), channel dimensions (W and L), the oxide capacitance (Cox), and the carrier mobility (?). In the linear region, ID is proportional to both the overdrive voltage (VGS - VT) and VDS, while in saturation the current is typically modeled using a quadratic dependence on (VGS - VT). Accurate determination of ID under various bias conditions is crucial for circuit design and performance prediction.

Oxide Capacitance

The oxide capacitance per unit area (Cox) is a critical parameter in MOSFET devices that relates to the gate oxide thickness (tox) and the dielectric constant of the oxide. It determines how effectively the gate voltage can modulate the channel charge. A thinner oxide increases Cox, thereby enhancing the device's transconductance and overall performance. Cox directly influences the calculation of drain current by affecting the charge density in the channel.

Carrier Mobility

Carrier mobility (?) is a measure of how quickly charge carriers (electrons in n-channel devices) can move through the semiconductor material when subjected to an electric field. It directly influences the magnitude of the drain current; higher mobility leads to higher current for a given electric field. In many calculations, a constant mobility is assumed, although in practical devices, mobility can vary with electric field and device geometry.

Carrier Velocity Saturation

At high electric fields, the drift velocity of carriers in the channel can reach a maximum value, a phenomenon known as velocity saturation. This behavior causes deviations from the ideal quadratic current-voltage relationship assumed in long-channel models. To account for velocity saturation, modified models such as the piecewise linear model are used. This model alters the drain current calculation by limiting the carrier velocity, which is particularly important for short-channel devices or at high drain voltages.
