The pier is made of material having a specific weight γ. If it has a square cross section, deter

step 1 So here in this question the average normal stress in the pier is given by the equation sigma is

The pier is made of material having a specific weight γ. If...

The pier is made of material having a specific weight $\gamma$. If it has a square cross section, determine its width $w$ as a function of $z$ so that the average normal stress in the pier remains constant. The pier supports a constant load $\mathbf{P}$ at its top where its width is $w_{1}$

Key Concepts

Variable Cross-Sectional Geometry

Variable cross-sectional geometry involves designing members whose cross-sectional dimensions change along the length to achieve desired performance characteristics, such as maintaining constant stress levels. By varying the geometry (for example, the width of a square cross-section) as a function of depth or height, engineers can optimize the distribution of material so that the internal stress does not exceed a specified level anywhere in the structure. This principle is widely applied in structural optimization to reduce weight and cost while ensuring integrity.

Normal Stress

Normal stress is the internal force per unit area within a structural member that resists applied loads. It is typically computed as the load divided by the cross-sectional area. In structural engineering, maintaining a constant normal stress across different sections of a member is crucial for ensuring safe and efficient material usage, as it prevents localized overloading and potential failure.

Distributed Loads (Self Weight)

Distributed loads refer to forces spread continuously over a structural element rather than concentrated at a point. In many structures, the self weight of the material acts as a distributed load, where the specific weight (weight per unit volume) contributes to the load experienced along the height of the member. Accounting for these loads is essential in determining how the structure will perform under its own weight as well as additional applied loads.
