The pressure and average velocity at point $A$ in the pipe shown in Fig. $\mathrm{P} 3.49$ are $16.0 \mathrm{psia}$ and $4.0 \mathrm{ft} / \mathrm{sec},$ respectively. Find the height $h$ and the pressure and average velocity at point $B$. Fluid fills the 1 -in.-diameter discharge pipe.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Bernoulli's Equation

This principle relates the pressure, velocity, and elevation head in a steady, incompressible, and inviscid flow along a streamline. It is used to determine how the fluid’s energy is conserved as it flows from one point to another, making it essential for calculating variables like pressure and velocity when there are changes in elevation or cross-sectional area in the pipe.

Continuity Equation

This equation is based on the conservation of mass for incompressible fluids. It states that the mass flow rate remains constant along the streamline, so the product of the cross-sectional area and the fluid velocity is constant. This concept is critical when dealing with changes in pipe diameter, as it directly links the velocities at different sections of the pipe.

Hydrostatic Pressure and Elevation Effects

This concept explains how pressure in a fluid is affected by the height (or depth) due to gravity. When the fluid moves vertically, the gravitational potential energy changes, which must be accounted for along with kinetic and pressure energy. It is crucial for determining the height difference needed to achieve specific pressure differences in the flow.
