The projection lens in a certain slide projector is a single thin lens. A slide $24.0 \mathrm{~mm}$ high is to be projected so that its image fills a screen $1.80 \mathrm{~m}$ high. The slide-toscreen distance is $3.00 \mathrm{~m}$. (a) Determine the focal length of the projection lens. (b) How far from the slide should the lens of the projector be placed to form the image on the screen?

Key Concepts

Thin Lens Equation

The thin lens equation relates the focal length (f) of a lens to the distances between the lens and the object (d_o) and between the lens and the image (d_i). It is typically written as 1/f = 1/d_o + 1/d_i. This fundamental equation in geometrical optics is used to analyze and design optical systems such as cameras, projectors, and microscopes.

Magnification

Magnification in lens systems is defined as the ratio of the height (or size) of the image to the height (or size) of the object and is also equal to the ratio of the image distance (d_i) to the object distance (d_o). It explains how a lens can enlarge or reduce the size of an object when forming an image.

Focal Length

The focal length of a lens is a measure of its converging or diverging power. In the context of a thin lens, the focal length determines the position where parallel rays converge (for a converging lens) or appear to diverge from (for a diverging lens). It is a key parameter in designing optical systems as it influences both image size and the distances required for proper image formation.

Image Formation Using Lenses

Image formation in lenses involves the convergence or divergence of light rays from an object to form a real or virtual image. In projection systems, a real image is formed on a screen when light from the object passes through a lens and is projected onto a surface. Understanding the relationships between object distance, image distance, and focal length is crucial in ensuring the projected image has the desired size and clarity.
