The resistors mentioned in problem 2 are connected in parallel across a 120-volt DC supply.
a. Calculate the current through each resistor.
b. Find the total current.
c. Find the total circuit resistance.
__________________________

Key Concepts

Ohm's Law

Ohm's Law is a fundamental principle in electrical circuits that relates voltage, current, and resistance using the equation V = IR. This law is essential for calculating the current flowing through a resistor when the voltage across it and its resistance are known, or vice versa.

Parallel Circuits

In parallel circuits, all components are connected across the same voltage source, which means each branch experiences the same voltage. The total current supplied by the source is divided among the parallel branches, and understanding this configuration is key to analyzing how current flows in different parts of the circuit.

Equivalent Resistance in Parallel Circuits

The concept of equivalent resistance in parallel circuits involves simplifying multiple resistors into a single resistance that has the same effect on the circuit. This is done using the formula 1/R_eq = 1/R1 + 1/R2 + ... + 1/Rn, and the resulting equivalent resistance is always lower than the smallest individual resistor in the circuit.

Current Distribution in Parallel Circuits

Current distribution in parallel circuits refers to the way the total current divides among the different branches according to their respective resistances. Each branch’s current can be calculated individually using Ohm's Law, as they all experience the same voltage, which is critical for determining the total and branch currents in the circuit.
