The rotation of link A O is controlled by the piston rod of...

The rotation of link $A O$ is controlled by the piston rod of hydraulic cylinder $B C,$ which is elongating at the constant rate $\dot{s}=k$ for an interval of motion. Write the vector expression for the acceleration of end $A$ for a given value of $\theta$ using unit vectors $\mathbf{e}_{n}$ and $\mathbf{e}_{t}$ with $n-t$ coordinates.

Key Concepts

Tangential and Normal Components of Acceleration

When a point moves along a curved path, its acceleration can be decomposed into tangential and normal (or centripetal) components. The tangential component is responsible for changes in the speed along the path, while the normal component points toward the center of curvature and accounts for the change in direction. This decomposition is essential for analyzing motions in polar or curvilinear coordinates, such as expressing the acceleration in terms of unit vectors aligned with these directions.

Rotational Kinematics

Rotational kinematics is concerned with the motion of bodies that rotate around a fixed axis. It involves quantities like angular displacement, angular velocity, and angular acceleration, and describes how these quantities affect the motion of points on the rotating body. In problems involving rotating links or rigid bodies, the instantaneous acceleration of any point can be expressed in terms of these angular quantities along with the geometry (e.g., radius) of the system.

Differentiation of Unit Vectors in Curvilinear Coordinates

In polar or curvilinear coordinates, the unit vectors (normally denoted as the normal and tangential directions) themselves change direction as the point moves along the curve. Their differentiation with respect to time introduces additional terms into the acceleration expression. Understanding how to differentiate these time-varying unit vectors is crucial when writing the vector acceleration expression for a point on a rotating body, especially when using a coordinate system aligned with the instantaneous motion.
