The smooth cylinder is suspended from the rail and is partially submerged in the water. If the wind blows at $8 \mathrm{~m} / \mathrm{s}$, determine the terminal velocity of the cylinder. The water and air are both at $20^{\circ} \mathrm{C}$.

Key Concepts

Fluid Properties

Fluid properties, including density and viscosity, are critical factors in determining how fluids interact with objects. Both the water's and air's characteristics influence the magnitude of drag forces and the overall behavior of objects in these media. Understanding these properties allows for accurate predictions of dynamic responses such as terminal velocity under varying environmental conditions.

Drag Coefficient

The drag coefficient is a dimensionless number that characterizes the drag or resistance of an object in a fluid environment. It encapsulates the effects of shape, surface roughness, and flow conditions, allowing for a more generalized evaluation of drag forces across different scenarios. Its determination is key when predicting forces in aerodynamics and hydrodynamics.

Force Equilibrium

Force equilibrium is the state in which all the forces acting on an object balance, resulting in no net force or acceleration. For objects experiencing fluid resistance, this equilibrium is reached when driving forces such as wind drag are exactly countered by resistive forces like viscous drag from a fluid. This balance is crucial for analyzing steady-state behaviors like terminal velocity.

Terminal Velocity

Terminal velocity is the steady speed an object reaches when the net force acting on it becomes zero. In fluid dynamics, this occurs when the driving force (such as wind force for a suspended object) and the resistive forces (such as drag from air or water) balance each other. The concept is essential in analyzing how objects behave under the influence of fluid flows.

Drag Force

Drag force refers to the resistance experienced by an object moving through a fluid, which depends on the fluid's density, the object's shape and size, and the square of the object's velocity. It is traditionally calculated using the drag equation, which is fundamental in understanding how fluid resistance can counteract applied forces to eventually establish a terminal velocity.
