The stagnation pressure and temperature of air flowing past a probe are $120 \mathrm{kPa}(\mathrm{abs})$ and $100^{\circ} \mathrm{C},$ respectively. The air pressure is $80 \mathrm{kPa}(\text { abs }) .$ Determine the airspeed and the Mach number considering the flow to be (a) incompressible, (b) compressible.

Key Concepts

Stagnation Conditions

Stagnation pressure and temperature are the total pressure and temperature a fluid attains when it is brought to rest isentropically. They account for both the static conditions and the kinetic energy of the flow, and are essential in relating the measurements at a probe to the free-stream conditions in both compressible and incompressible analyses.

Static Conditions

Static pressure and temperature are the local properties of the fluid away from any stagnation effects and are used as the baseline conditions for the flow. They are related to the stagnation properties via energy equations and isentropic relations, and their differences can be used to calculate the flow velocity.

Incompressible Flow

In incompressible flow analysis, the fluid density is assumed constant and the Bernoulli equation is used to relate the pressure difference between stagnation and static states directly to the fluid’s kinetic energy. This assumption simplifies the calculation of flow velocity when compressibility effects are negligible.

Compressible Flow

Compressible flow analysis accounts for variations in fluid density and uses isentropic relations to connect stagnation and static properties with the Mach number. This approach is necessary when the fluid velocity is high enough that compressibility effects (i.e., changes in density) cannot be neglected.

Mach Number

The Mach number is a dimensionless quantity defined as the ratio of the flow velocity to the local speed of sound. It quantifies the level of compressibility effects present in the flow and is key in determining which theoretical model (incompressible or compressible) is appropriate for analysis.

Speed of Sound

The speed of sound in a fluid is the rate at which pressure disturbances propagate through it and is dependent on the local temperature and thermodynamic properties. It plays a fundamental role in compressible flow calculations, particularly in the determination of the Mach number.
