The stepped shaft shown rotates at 450 rpm. Knowing that r=0.2 in. determine the largest torque

step 1 So let's solve this question. So in this question we have d by d equals to 100 by 60 that equals

The stepped shaft shown rotates at 450 rpm. Knowing that...

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Torsion in Circular Shafts

This concept refers to the twisting of a shaft due to an applied torque. The distribution of shear stresses within the shaft is controlled by torsional loading, and understanding this behavior is fundamental in ensuring that shafts can transmit the required torque without failure.

Polar Moment of Inertia

The polar moment of inertia is a geometric property of a cross-section that measures its resistance to torsional deformation. In circular shafts, it depends strongly on the radius (to the fourth power), making it a critical factor in determining the shaft’s torsional strength.

Shear Stress–Torque Relationship

In the torsion analysis of shafts, the relation ? = T*r/J connects the applied torque, the shaft's radius, and its polar moment of inertia with the resulting shear stress. This equation is essential for verifying that the induced shear stress does not exceed the material’s allowable limits.

Design Considerations for Torque Transmission

When designing shafts to transmit torque, it is crucial to use the most vulnerable section (often the one with the smallest diameter in stepped shafts) as the basis for calculations. This ensures that the shaft operates within safe stress limits, thereby preventing structural failure.
