The student engineer of a campus radio station wishes to...

The student engineer of a campus radio station wishes to verify the effectiveness of the lightning rod on the antenna mast (Fig. P28.63). The unknown resistance $R_{x}$ is between points $C$ and $E$ . Point $E$ is a true ground, but it is inaccessible for direct measurement because this stratum is several meters below the Earth's surface. Two identical rods are driven into the ground at $A$ and $B$ , introducing an unknown resistance $R_{y}$ . The procedure is as follows. Measure resistance $R_{1}$ between points $A$ and $B$ , then connect $A$ and $B$ with a heavy conducting wire and measure resistance $R_{2}$ between points $A$ and $C .$ (a) Derive an equation for $R_{x}$ in terms of the observable resistances, $R_{1}$ and $R_{2} .$ (b) A satisfactory ground resistance would be $R_{x}<$ 2.00$\Omega$ . Is the grounding of the station adequate if measurements give $R_{1}=13.0 \Omega$ and $R_{2}=6.00 \Omega ?$

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Series and Parallel Resistor Combinations

Many measurement techniques involve resistors connected in series and parallel, and understanding how to combine these resistances is key to circuit analysis. In this context, knowing the rules for adding resistances helps in deriving equations that relate observable resistances to the unknown resistance, enabling the engineer to solve for it using measured values.

Resistive Network Analysis

This concept involves studying the arrangement of resistive elements in a circuit to determine equivalent resistances and uncover unknown values. It requires setting up and solving equations based on the circuit’s configuration. In problems like this, the network includes resistors connected in various ways, and analyzing how current flows through different paths is essential to deduce the unknown resistance.

Grounding Resistance Measurement

Grounding resistance measurement is the process of determining the effective resistance between a grounding electrode system and the earth. It is critical for safety and system performance in electrical installations. The method used in this procedure illustrates how additional test connections can enable indirect measurement of the earth's resistance when direct access to the true ground is impractical.
