The system in Fig. 12-77 is in equilibrium. The angles are θ1=60^∘ and θ2=20^∘, and the ball has

step 1 Here in this given problem these are the 2 digit supports horizontal ceiling and vertical wall.

The system in Fig. 12-77 is in equilibrium. The angles are...

The system in Fig. $12-77$ is in equilibrium. The angles are $\theta_{1}=60^{\circ}$ and $\theta_{2}=20^{\circ},$ and the ball has mass $M=2.0 \mathrm{kg} .$ What is the tension
in (a) string $a b$ and (b) string $b c ?$
