The table below shows temperature versus time for $500 \mathrm{~g}$ of water heated in a microwave oven. In a microwave, essentially all the microwave energy goes into the water-containing food in the oven. Plot the data, determine a best-fit line, and use the slope of your line to determine the microwave power of this particular oven. Assume that water's specific heat is independent of temperature (which is only approximately true; see Problem 75). $$ \begin{array}{|l|l|l|l|l|l|l|l|} \hline \text { Time (s) } & 0 & 25 & 60 & 95 & 125 & 160 & 190 \\ \hline \text { Temperature }\left({ }^{\circ} \mathrm{C}\right) & 12 & 20 & 39 & 53 & 64 & 83 & 93 \\ \hline \end{array} $$

The table below shows temperature versus time for $500 \mathrm{~g}$ of water heated in a microwave oven. In a microwave, essentially all the microwave energy goes into the water-containing food in the oven. Plot the data, determine a best-fit line, and use the slope of your line to determine the microwave power of this particular oven. Assume that water's specific heat is independent of temperature (which is only approximately true; see Problem 75). $$
\begin{array}{|l|l|l|l|l|l|l|l|}
\hline \text { Time (s) } & 0 & 25 & 60 & 95 & 125 & 160 & 190 \\
\hline \text { Temperature }\left({ }^{\circ} \mathrm{C}\right) & 12 & 20 & 39 & 53 & 64 & 83 & 93 \\
\hline
\end{array}
$$

Key Concepts

Power Determination from Energy Transfer

Power is defined as the rate at which energy is transferred or converted, typically measured as energy per unit time. In experiments where energy is added to a system, such as heating water in a microwave, the slope of the temperature versus time best-fit line can be used alongside the specific heat capacity and mass of the water to calculate the microwave's power output.

Linear Regression (Best-Fit Line)

Linear regression is a statistical method used to describe the relationship between a dependent variable and an independent variable by fitting a linear equation to observed data. The best-fit line minimizes the distances between the observed data points and the line itself, with the slope providing meaningful information about the rate of change between the variables.

Graphical Data Analysis

This concept involves plotting the experimental data, in this case temperature versus time, to visually observe trends and relationships. It is a crucial step in understanding how the variables interact and in providing a foundational basis for further analysis, such as fitting a line to the data.

Specific Heat Capacity and Calorimetry

Specific heat capacity is a property of a material that quantifies the amount of heat energy required to raise the temperature of a unit mass by one degree. In calorimetry, this relationship (expressed as Q = mc?T) underpins the determination of energy transfer in systems involving heat gain or loss, such as heating water.
