The three-arm lawn sprinkler of Fig. P3.153 receives $20^{\circ} \mathrm{C}$ water through the center at $2.7 \mathrm{m}^{3} / \mathrm{h}$. If collar friction is negligible, what is the steady rotation rate in $\mathrm{r} / \mathrm{min}$ for $(a) \theta=0^{\circ}$ and $(b) \theta=40^{\circ} ?$

Key Concepts

Conservation of Angular Momentum

This principle states that when no external torque is acting on a system, its angular momentum remains constant. In the context of a rotating sprinkler, the change in the water’s momentum as it flows through and exits the arms creates a reactive moment that imparts angular momentum to the sprinkler body.

Momentum Flux

Momentum flux is the rate at which momentum is transferred by the flowing fluid. It is determined by the mass flow rate and the velocity of the water. In systems like the sprinkler, the momentum flux is used to calculate the reactive force that arises from the change in fluid direction, which in turn creates the torque driving the rotation.

Torque Generation from Fluid Forces

When the water flowing through the sprinkler changes direction, it undergoes a change in momentum which generates a reactive force. When this force is applied at a distance from the axis of rotation, it creates a torque. This torque is responsible for the rotational motion of the sprinkler, and its magnitude depends on both the reaction force and the geometry of the sprinkler arms.

Steady-State Rotational Dynamics

A system reaches steady-state rotation when the net torque is zero, meaning all driving torques are balanced by any resisting torques. In the case of the sprinkler with negligible friction, the reactive torque generated by the water flow reaches an equilibrium with the dynamic response of the sprinkler, resulting in a constant angular speed that can be determined through momentum and force balance analysis.
