The time integral of a torque is called the angular impulse....

The time integral of a torque is called the angular impulse. ( $a$ ) Starting from $\overrightarrow{\boldsymbol{\tau}}=d \overrightarrow{\mathbf{L}} / d t$, show that the resultant angular impulse equals the change in angular momentum. This is the rotational analogue of the linear impulse-momentum relation. (b) For rotation around a fixed axis, show that $$ \int \tau d t=F_{\mathrm{av}} r(\Delta t)=I\left(\omega_{\mathrm{f}}-\omega_{\mathrm{i}}\right) $$ where $r$ is the moment arm of the force, $F_{\mathrm{av}}$ is the average value of the force during the time it acts on the object, and $\omega_{\mathrm{i}}$ and $\omega_{\mathrm{f}}$ are the angular velocities of the object just before and just after the force acts.

The time integral of a torque is called the angular impulse. ( $a$ ) Starting from $\overrightarrow{\boldsymbol{\tau}}=d \overrightarrow{\mathbf{L}} / d t$, show that the resultant angular impulse equals the change in angular momentum. This is the rotational analogue of the linear impulse-momentum relation.
(b) For rotation around a fixed axis, show that
$$
\int \tau d t=F_{\mathrm{av}} r(\Delta t)=I\left(\omega_{\mathrm{f}}-\omega_{\mathrm{i}}\right)
$$
where $r$ is the moment arm of the force, $F_{\mathrm{av}}$ is the average value of the force during the time it acts on the object, and $\omega_{\mathrm{i}}$ and $\omega_{\mathrm{f}}$ are the angular velocities of the object just before and just after the force acts.

Key Concepts

Moment of Inertia

The moment of inertia is a measure of an object’s resistance to changes in its rotational motion about an axis. It plays a role analogous to mass in linear dynamics. In fixed-axis rotations, the moment of inertia connects the applied torque to the resulting angular acceleration and subsequent change in angular velocity.

Torque-Angular Momentum Relationship

This concept is established by the rotational form of Newton's second law, which states that the net torque acting on an object is equal to the time derivative of its angular momentum. By integrating this relationship over time, one obtains the angular impulse-momentum theorem, demonstrating that the angular impulse equals the change in angular momentum.

Rotational Kinematics and Fixed-Axis Rotation

Rotational kinematics describes the relationships between angular displacement, velocity, and acceleration in rotational motion. For fixed-axis rotation, the analysis involves relating forces (through a moment arm), torque, and average forces to determine the changes in angular velocity, mirroring the techniques used in linear impulse and momentum problems.

Angular Impulse

Angular impulse is the measure of the effect of a torque acting over a period of time. It is defined as the time integral of torque and is analogous to linear impulse. Angular impulse quantifies the change imparted to a system's rotation, leading directly to a change in angular momentum.

Angular Momentum

Angular momentum is a physical quantity that represents the extent of an object’s rotational motion about a given axis. It depends on the moment of inertia and the angular velocity of the body. Changes in angular momentum are produced by the application of a net external torque.
