The two pulleys are riveted together to form a single rigid unit, and each of the two cables is securely wrapped around its respective pulley. If point $A$ on the hoisting cable has a velocity $v=3 \mathrm{ft} / \mathrm{sec}$ determine the magnitudes of the velocity of point 0 and the velocity of point $B$ on the larger pulley for the position shown.

Key Concepts

Relative Motion Analysis

Relative motion analysis involves breaking down the motion of a system into components relative to a moving or fixed reference frame. This is particularly useful in systems where parts are both translating and rotating as it allows for the determination of velocities at particular points (for example, on different parts of a pulley) by considering both the motion of the system as a whole and the internal motion due to rotation.

Kinematic Constraint Relations

Kinematic constraint relations are equations that arise from the physical constraints in a system, such as the inextensibility of a cable or the fixed connection between pulleys. These relations ensure that the motions of different parts of the system are interdependent, enabling the determination of unknown velocities when one part of the system is in motion.

Rigid Body Kinematics

Rigid body kinematics examines the motion of bodies where the distances between points remain constant, allowing the analysis of overall translational and rotational movement. This concept is essential in determining how different points on a rotating or moving object (such as a pulley system) change their positions with respect to time.

Non-Slip Condition

The non-slip condition assumes that the interface between a moving cable (or belt) and a pulley does not experience any relative sliding. Because of this, the linear velocity of the cable exactly matches the tangential velocity of the pulley at the point of contact, which is crucial for establishing relationships between the motion of the cable and the rotation of the pulley.
