The wave equation describing the transverse vibrations of a stretched membrane under tension $T$ and having a uniform surface density $\rho$ is $$ T\left(\frac{\partial^{2} u}{\partial x^{2}}+\frac{\partial^{2} u}{\partial y^{2}}\right)=\rho \frac{\partial^{2} u}{\partial t^{2}} $$ Find a separable solution appropriate to a membrane stretched on a frame of length $a$ and width $b,$ showing that the natural angular frequencies of such a membrane are given by $$ \omega^{2}=\frac{\pi^{2} T}{\rho}\left(\frac{n^{2}}{a^{2}}+\frac{m^{2}}{b^{2}}\right) $$ where $n$ and $m$ are any positive integers.

The wave equation describing the transverse vibrations of a stretched membrane under tension $T$ and having a uniform surface density $\rho$ is
$$
T\left(\frac{\partial^{2} u}{\partial x^{2}}+\frac{\partial^{2} u}{\partial y^{2}}\right)=\rho \frac{\partial^{2} u}{\partial t^{2}}
$$
Find a separable solution appropriate to a membrane stretched on a frame of length $a$ and width $b,$ showing that the natural angular frequencies of such a membrane are given by
$$
\omega^{2}=\frac{\pi^{2} T}{\rho}\left(\frac{n^{2}}{a^{2}}+\frac{m^{2}}{b^{2}}\right)
$$
where $n$ and $m$ are any positive integers.

Key Concepts

Normal Modes and Natural Frequencies

Normal modes refer to the specific, independent patterns of vibration in a system that occur at characteristic frequencies, known as natural frequencies. For a stretched membrane, each normal mode corresponds to a specific spatial pattern determined by the eigenfunctions of the spatial part of the wave equation. The natural frequencies are obtained from the eigenvalues and are essential for understanding the vibrational behavior of the system.

Eigenvalue Problems

When separation of variables is applied to PDEs with boundary conditions, the resulting ordinary differential equations often become eigenvalue problems. These problems require finding nontrivial solutions (eigenfunctions) and corresponding eigenvalues that satisfy both the differential equations and the imposed boundary conditions. The eigenvalues typically represent quantized physical properties such as frequencies or energies.

Boundary Conditions

Boundary conditions specify the behavior of the solution at the limits of the physical domain, ensuring that the solution is physically feasible. For a membrane stretched on a rectangular frame, the displacement is typically set to zero at the edges, which are known as Dirichlet boundary conditions. These conditions are essential for determining the specific form of the separation constants and, consequently, the allowed modes of vibration.

Separation of Variables

Separation of variables is a mathematical technique used to solve partial differential equations by assuming that the solution can be written as a product of functions, each depending on a single independent variable. This methodology reduces a complex multi-variable problem into simpler ordinary differential equations, which can then be solved individually. It is particularly effective for problems with separable coordinate systems and homogeneous boundary conditions.

Wave Equation

The wave equation is a second?order partial differential equation that describes the propagation of waves through a medium, such as the vibrations of a stretched membrane. It relates the spatial derivatives, which describe the curvature of the wave, to the temporal derivative, which describes the acceleration of the medium. This fundamental equation is central in fields such as acoustics, electromagnetism, and mechanical vibrations.
