The waveform for the current in the 2 -H inductor shown in Fig. $P 6.36 a$ is given in Fig. $P 6.36 b .$ Determine the following quantities: (a) the energy stored in the inductor at $t=1.5 \mathrm{ms}$ (b) the energy stored in the inductor at $t=7.5 \mathrm{ms}$ (c) $v_{L}(t)$ at $t=1.5 \mathrm{ms},$ (d) $v_{L}(t)$ at $t=6.25 \mathrm{ms},$ and (e) $v_{L}(t)$ at $t=2.75 \mathrm{ms}$

The waveform for the current in the 2 -H inductor shown in Fig. $P 6.36 a$ is given in Fig. $P 6.36 b .$ Determine the following quantities:
(a) the energy stored in the inductor at $t=1.5 \mathrm{ms}$
(b) the energy stored in the inductor at $t=7.5 \mathrm{ms}$
(c) $v_{L}(t)$ at $t=1.5 \mathrm{ms},$ (d) $v_{L}(t)$ at $t=6.25 \mathrm{ms},$ and (e) $v_{L}(t)$
at $t=2.75 \mathrm{ms}$

Key Concepts

Voltage-Current Relationship in an Inductor

The voltage across an inductor is directly related to the rate of change of current through it, expressed by the equation v(t) = L (di/dt). This principle is essential for determining how voltage in an inductive component responds dynamically to changes in current, particularly during transient events.

Time-Domain Signal Analysis

The analysis of time-varying signals, such as a current waveform with specific time intervals, is crucial for evaluating instantaneous electrical quantities. This includes determining energy stored at particular moments and computing the derivative of the waveform to find associated voltages.

Transient Analysis in Circuits

Transient analysis addresses how circuit variables like current and voltage evolve over time, especially immediately after a change or during non-steady-state conditions. This involves understanding and interpreting time-domain waveforms and applying the principles of energy storage and derivative-based voltage calculations.

Energy Storage in an Inductor

This concept involves calculating the energy stored in the magnetic field of an inductor using the formula E = ½ L i². It is fundamental in circuit analysis, as it quantifies how much energy is held in the inductor at any given instant, depending on both its inductance and the instantaneous value of the current.
