There is a cylinder-piston arrangement. Determine the pressure within the cylinder and the power required to move the piston, if piston $C$ moves outwards (to the right) at a constant speed of $7 \mathrm{~m} / \mathrm{s}$, and as it does, outside air at atmospheric pressure flows into the circular cylinder through the opening at $B$. Take $\rho_{a}=1.23 \mathrm{~kg} / \mathrm{m}^{3}$. Hint: Recall that power is force $F$ times velocity $V$, where $F=p A$.

Key Concepts

Pressure in Fluid Systems

This concept concerns the force distributed over an area within a fluid. Pressure (defined as force per unit area, p = F/A) is a central parameter in fluid mechanics that dictates how forces act on system boundaries like a piston. Understanding pressure is essential when analyzing how internal pressures balance against atmospheric or other external pressures in devices such as piston-cylinder arrangements.

Dynamic Pressure

Dynamic pressure, calculated as (1/2)?V², represents the kinetic energy per unit volume of a moving fluid. It is a key concept when assessing the pressure drop required to accelerate a fluid from rest to a finite velocity. In systems where fluid is drawn into an expanding volume, such as when a piston creates a moving boundary, dynamic pressure explains how the fluid’s velocity translates into a pressure difference that must be overcome or is naturally induced in the system.

Flow Rate and Continuity

The principle of continuity states that for an incompressible fluid, the volume flow rate remains constant throughout the flow field. When a piston moves and changes the volume of a cylinder, the rate at which the fluid must flow in (or out) is directly related to the piston’s cross-sectional area and its velocity. This connection between piston motion and the corresponding fluid flow is essential for linking the dynamic behavior of the system with energy and pressure considerations.

Work and Power in Fluid Systems

Work in a fluid system is performed when a force moves a boundary, and power is the rate of doing this work. The relation power = force × velocity, with force expressed as pressure times area, (F = pA), connects the mechanical energy input with the movement of the piston. This concept is crucial for determining the energy requirements of systems where pressures are being balanced and fluid is being set into motion by mechanical devices.
