Three identical point charges $q$ are placed at each of three corners of a square of side $L$. Find the magnitude and direction of the net force on a (b) at the vacant point charge $-3 q$ placed (a) at the center of the square and comer of the square. In each case, draw a free-body diagram showing the forces exerted on the $-3 q$ charge by each of the other three charges.

Three identical point charges $q$ are placed at each of three corners of a square of side $L$. Find the magnitude and direction of the net force on a
(b) at the vacant point charge $-3 q$ placed (a) at the center of the square and comer of the square. In each case, draw a free-body diagram showing the forces exerted on the $-3 q$ charge by each of the other three charges.

Key Concepts

Free-Body Diagrams

Free-body diagrams are a visual tool used to represent all the forces acting on an individual charge. By representing each force as an arrow emanating from the charge in the direction of the force, these diagrams help in systematically applying Newton's laws and in conducting vector addition to determine the net force on the charge.

Square Geometry in Electrostatics

Square geometry plays an important role in determining distances and directions of forces in problems involving charges at the vertices of a square. Understanding the properties of a square, such as equal side lengths and the relationship between diagonals and sides, is crucial for calculating the distances between charges and for evaluating the resultant forces accurately.

Vector Addition of Forces

Vector addition of forces is essential because forces are vector quantities, having both magnitude and direction. The net force is found by graphically or analytically summing the individual force vectors, taking into account their directional components. This approach is critical in problems where forces act in different directions, such as those involving multiple charges positioned at various locations.

Superposition Principle

The superposition principle in electrostatics states that the net force experienced by a charge in a system of other charges is the vector sum of the forces exerted by each individual charge. This allows for the analysis of complex charge configurations by breaking them into simpler pairwise interactions and then summing the resulting forces.

Coulomb's Law

Coulomb's law provides the mathematical basis for determining the force between two point charges. It states that the electrostatic force between two charges is directly proportional to the product of the magnitudes of the charges and inversely proportional to the square of the distance between them. This law is fundamental in calculating the magnitude and direction of the forces in systems involving multiple charges.

Symmetry in Charge Distribution

Symmetry in charge distribution is a key concept that simplifies the analysis of electrostatic problems. When charges are arranged in a symmetrical pattern, certain components of the forces may cancel out or add constructively, making it easier to determine the net force on a test charge without computing every individual contribution in full detail.
