Three monkeys A, B, and C weighing 20,25, and 15 Ib,...

Three monkeys $A, B,$ and $C$ weighing $20,25,$ and 15 Ib, respectively, are climbing up and down the rope suspended from $D$. At the instant represented, $A$ is descending the rope with an acceleration of $5 \mathrm{ft} / \mathrm{sec}^{2}$ and $C$ is pulling himself up with an acceleration of $3 \mathrm{ft} / \mathrm{sec}^{2} .$ Monkey $B$ is climbing up with a constant speed of $2 \mathrm{ft} / \mathrm{sec}$. Treat the rope and monkeys as a complete system and calculate the tension $T$ in the rope at $D$.

Three monkeys $A, B,$ and $C$ weighing $20,25,$ and 15 Ib, respectively, are climbing up and down the rope suspended from $D$. At the instant represented, $A$ is descending the rope with an acceleration of $5 \mathrm{ft} / \mathrm{sec}^{2}$ and $C$ is pulling himself up with an acceleration of
$3 \mathrm{ft} / \mathrm{sec}^{2} .$ Monkey $B$ is climbing up with a constant speed of $2 \mathrm{ft} / \mathrm{sec}$. Treat the rope and monkeys as a complete system and calculate the tension $T$ in the rope at $D$.

Key Concepts

Newton's Second Law

Newton's Second Law states that the net external force acting on a body (or system) is equal to the product of its mass and its acceleration. In problems of dynamics, this principle is used to relate the forces (like weight and tension) to the acceleration of the system, allowing us to set up equations and solve for unknowns such as tension.

Free-Body Diagram and System Analysis

Constructing a free-body diagram is essential in dynamics problems because it helps to visualize and account for all forces acting on a system. In a system where multiple objects are interconnected by a rope, drawing the free-body diagram of the entire system allows you to isolate the net external forces (while internal forces cancel out) and effectively apply Newton's Second Law.

Internal versus External Forces

When analyzing a closed system, it is important to recognize that forces acting between components of the system (internal forces) cancel each other out, leaving only external forces (such as gravity and an applied tension) to affect the motion of the center of mass. This concept simplifies the problem by reducing the need to consider the individual accelerations of each component within the system.

Center-of-Mass Dynamics

The dynamics of the center of mass of a system can be analyzed by summing all external forces and dividing by the total mass. Even if individual parts of the system move with different accelerations, the overall motion of the system is governed by the net external force. This approach is particularly useful in problems where multiple bodies are accelerating differently, as it provides a way to aggregate their motions into one effective acceleration for the entire system.
