Three shafts and four gears are used to form a gear train...

Three shafts and four gears are used to form a gear train that will transmit power from the motor at $A$ to a machine tool at $F$. (Bearings for the shafts are omitted in the sketch.) The diameter of each shaft is as follows: $d_{A B}=16 \mathrm{mm}, d_{C D}=20 \mathrm{mm}, d_{E F}=28 \mathrm{mm} .$ Knowing that the frequency of the motor is $24 \mathrm{Hz}$ and that the allowable shearing stress for each shaft is $75 \mathrm{MPa}$, determine the maximum power that can be transmitted.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Power Transmission in Rotating Shafts

Power transmission in rotating shafts involves transferring energy from a power source to a load using rotational motion. The power delivered is the product of the applied torque and the angular velocity, highlighting the importance of both mechanical strength and rotational speed in a successful design.

Gear Train Dynamics

Gear train dynamics examines how a set of interlocking gears transmits power and modifies rotational speed and torque between different shafts. By selecting appropriate gear ratios, designers can ensure that the power delivered by a motor is effectively reduced or amplified to meet the requirements of the driven machine.

Torsional Stress

Torsional stress is the shear stress induced in a circular shaft when a torque is applied. This stress is calculated by relating the applied torque to the shaft’s polar moment of inertia and its outer radius, helping engineers ensure that the shaft can withstand operational loads without yielding or failing.

Polar Moment of Inertia

The polar moment of inertia is a geometric property of a shaft's cross-section that measures its resistance to torsion. It plays a critical role in determining how much torque a shaft can carry without experiencing excessive angular deformation or failure due to shear stress.
