To reduce the total mass of the assembly of Prob. 3.11, a...

To reduce the total mass of the assembly of Prob. $3.11,$ a new design is being considered in which the diameter of shaft $B C$ will be smaller. Determine the smallest diameter of shaft $B C$ for which the maximum value of the shearing stress in the assembly will not increase.

Key Concepts

Polar Moment of Inertia

The polar moment of inertia is a geometric property of a cross-section that quantifies its resistance to torsional deformation. For circular shafts, it is computed based on the diameter raised to a power, indicating a strong sensitivity to changes in diameter. A proper understanding of the polar moment of inertia is critical for predicting the shearing stress under torsion and for optimizing shaft dimensions.

Design Optimization under Stress Constraints

Design optimization under stress constraints involves balancing material usage, weight, and dimensional parameters to meet specified performance criteria without increasing the risk of failure. In shaft design, optimizing the diameter while ensuring that maximum shearing stress does not increase is a typical problem that requires careful analysis of material properties, load distributions, and geometric factors.

Shearing Stress

Shearing stress is a measure of how internal forces are distributed across a material when subjected to an applied load. In the context of shaft design, it is the stress that arises as a result of torsional (twisting) loads. Managing and calculating shearing stress is crucial in ensuring that the design does not exceed the material’s strength limits, thereby preventing failure.

Torsion in Circular Shafts

Torsion in circular shafts refers to the mechanical behavior of a shaft when a torque is applied to it, causing it to twist. The analysis of torsion involves determining how the applied torque is distributed across the cross-section, typically resulting in a maximum shearing stress at the outer surface. This concept is foundational in designing shafts that can handle specified loads safely.
