Two cylinders are filled with liquid water, $\rho=$ $1000 \mathrm{kg} / \mathrm{m}^{3},$ and connected by a line with a closed valve, as shown in Fig. P2.76. $A$ has $100 \mathrm{kg}$ and $B$ has $500 \mathrm{kg}$ of water, their cross-sectional areas $\operatorname{are} A_{A}=0.1 \mathrm{m}^{2}$ and $A_{B}=0.25 \mathrm{m}^{2},$ and the height $h$ is $1 \mathrm{m} .$ Find the pressure on each side of the valve. The valve is opened and water flows to an equilibrium. Find the final pressure at the valve location.

Key Concepts

Hydrostatic Pressure

This concept explains that the pressure at a certain depth in a fluid at rest is proportional to the vertical height of the fluid above that point, given by the relation p = ?gh, where ? is the fluid density, g is the acceleration due to gravity, and h is the height of the fluid column. It is fundamental in calculating the pressure exerted by a static fluid.

Pressure Equilibrium

This principle states that when different fluid systems are connected and allowed to interact, they will adjust until the pressures at the connection points equalize. In the context of connecting vessels, once the valve is open, the fluid redistributes so that the hydrostatic pressures in both vessels become equal.

Conservation of Mass

This concept ensures that the total mass of the fluid remains constant throughout the process of fluid redistribution. When fluids are transferred between connected vessels, the mass balance governs how the fluid levels adjust, directly influencing the final hydrostatic pressures.

Effect of Cross-sectional Area on Fluid Height

The cross-sectional area of a container directly affects the height of the fluid column for a given mass. In containers with different areas, the same mass of fluid will result in different fluid heights, which in turn impacts the calculation of hydrostatic pressure in each vessel.

Transcript

00:01 So in this problem, we have this system here where we have a valve that's closed.

00:07 We want to find the pressure on either side of the valve.

00:11 So what we're first going to do is we're going to write an expression to find what the height of each water column in the chambers is.

00:19 So we can do this by writing two expressions for the volume.

00:25 The first where we take the mass and divide it by the density.

00:29 The second where we take the height, which is what we're looking for, multiply it by the cross -sectional area.

00:36 So when we rearrange for h, we get an expression that looks like this.

00:41 We have the mass divided by density and the cross -sectional area.

00:46 So when we plug in for the values that we have for chamber a, so the mass of water and the cross -sectional area of chamber a, we'll find that we have a height of one meter, so that's the height of the column of water.

01:04 And in chamber b, we'll find that it's two meters.

01:12 So now that we have the height of the water, we can go ahead and solve for the pressure on either side of these two red points.

01:20 So we'll first solve for the pressure due to chamber a, so on this side.

01:27 And what we'll do is we'll take the atmospheric pressure and we'll add an expression for delta p where we take the density of water times gravitational acceleration times the height of a which we just found.

01:46 So when we do that we're going to get a pressure of 111 .1 kilopascals.

01:57 And now for chamber b it's going to be pretty similar but just for the term h, where we do the height.

02:09 It's not just going to be two meters, since this chamber is lifted a level h off the ground, which we know is one meter.

02:19 So the term that we would use here for the height would be hb plus h.

02:27 So 2 plus 1, that would just be 3.

02:30 And we'll get a pressure of 130 .8 kilopascals.

02:35 So now in the second part of this problem, we want to find what the pressure at the valve would be once we open it.

02:44 So that means that the system will be in equilibrium and the height, the level of water will be equal...
