Two lamps have different resistances, one larger than the other.
a. If the lamps are connected in parallel, which is brighter (dissipates more power)?
b. When the lamps are connected in series, which lamp is brighter?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Series Circuits

In a series circuit, components are connected end-to-end, so the same current flows through each component regardless of their individual resistances. The voltage drop across each component is proportional to its resistance. As a result, a component with a higher resistance in series will have a larger voltage drop and dissipate more power.

Parallel Circuits

In a parallel circuit, all components are connected across the same voltage source. This means each component experiences the same voltage, and the current through each component is determined by its resistance. Lower resistance in a parallel connection results in higher current, leading to greater power dissipation.

Ohm's Law

Ohm's Law is a fundamental principle in electrical circuits that relates voltage (V), current (I), and resistance (R) through the equation V = IR. It is essential for understanding how changes in resistance affect the current flow in a circuit when a constant voltage is applied.

Power Dissipation in Resistive Circuits

Power dissipation in a resistor is given by formulas such as P = V²/R and P = I²R. This concept explains how energy is converted into heat in a resistive element. In analyzing circuits, knowing how power dissipates helps predict which component may generate more heat or be brighter in the case of lamps.
