Two steel plates of $12 \times 220$ -mm rectangular cross section are welded to the $\mathrm{W} 250 \times 58$ beam as shown. Determine the largest allowable vertical shear if the shearing stress in the beam is not to exceed $90 \mathrm{MPa}$

Key Concepts

Shear Stress in Beams

Shear stress in beams is the internal force per unit area that develops when beams are subjected to transverse loads. This concept is essential in designing and analyzing beams, where formulas relate the applied shear force to the cross-sectional geometry, particularly the moment of inertia and the first moment of area, to ensure that the material’s strength is not exceeded.

Allowable Stress Design

Allowable stress design is a method in structural engineering where the stresses in a component are limited to a predetermined maximum value to ensure safety. In this context, the maximum allowable shear stress (90 MPa) is used as a design constraint, and all calculations must ensure that the applied loads do not generate stresses that exceed this limit.

Composite Section Behavior

Composite section behavior refers to how different connected or welded components work together as a unified structural element. When steel plates are welded to a beam, they alter the overall cross-sectional properties, such as moment of inertia and stress distribution, which directly affects the beam's shear capacity and overall performance.

Welded Connections in Steel Structures

Welded connections are critical in steel structures as they provide the means to effectively join different components, ensuring load transfer and structural integrity. The design of these connections must consider not only the strength of the weld itself but also how the connection influences the composite behavior of the overall member under applied loads.
