Ultrasound pulses of with a frequency of $1.000 \mathrm{MHz}$ are transmitted into water, where the speed of sound is $1500 \mathrm{m} / \mathrm{s}$ The spatial length of each pulse is $12 \mathrm{mm}$. a. How many complete cycles are contained in one pulse? b. What range of frequencies must be superimposed to create each pulse?

Ultrasound pulses of with a frequency of $1.000 \mathrm{MHz}$ are transmitted into water, where the speed of sound is $1500 \mathrm{m} / \mathrm{s}$ The spatial length of each pulse is $12 \mathrm{mm}$.
a. How many complete cycles are contained in one pulse?
b. What range of frequencies must be superimposed to create each pulse?

Key Concepts

Bandwidth and Time–Frequency Tradeoff

The range of frequencies that must be superimposed to create a pulse is related to the pulse’s time duration through a time–frequency tradeoff. A shorter pulse in time requires a broader frequency range, approximately given by the reciprocal of the pulse duration. This principle is crucial in understanding and engineering systems where pulse shaping and bandwidth constraints are important.

Time Domain Pulse Duration and Frequency Spectrum

Any time-limited signal, such as a pulse, has an inherent frequency spectrum. The duration of the pulse in time is directly related to the spread of frequencies required to synthesize it. This inverse relationship between time duration and spectral bandwidth is an application of Fourier analysis in signal processing.

Wave Frequency and Wavelength Relationship

In a medium, the speed of a wave is given by the product of its frequency and wavelength. This basic relation allows us to compute one quantity if the other two are known, and it is fundamental in linking temporal and spatial characteristics of waves.

Pulse Length and Cycle Count

A pulse is a temporary burst of oscillations. The number of complete cycles contained within a pulse can be determined by dividing the spatial length of the pulse by the wavelength of the wave. This concept is important in designing and analyzing pulses in various fields such as acoustics and communications.
