Unpolarized light whose intensity is 1.10 W / m^2 is incident on the polarizer in Figure 24.20 .

step 1 Here incident light is unpolarized light. So after passing through the polarizer, it intensity i

Unpolarized light whose intensity is 1.10 W / m^2 is...

Unpolarized light whose intensity is $1.10 \mathrm{W} / \mathrm{m}^{2}$ is incident on the polarizer in Figure $24.20 .$ (a) What is the intensity of the light leaving the polarizer? (b) If the analyzer is set at an angle of $\theta=75^{\circ}$ with respect to the polarizer, what is the intensity of the light that reaches the photocell?

Key Concepts

Unpolarized Light

Unpolarized light consists of waves vibrating in multiple planes perpendicular to the direction of propagation. The random orientation means that, on average, only half of the incident light's electric field components are aligned with any given direction, which is critical when light interacts with polarizing devices.

Polarizer

A polarizer is an optical filter that allows light waves of a specific orientation to pass through while absorbing or reflecting waves oscillating in other directions. When unpolarized light passes through a polarizer, it becomes linearly polarized, and the intensity is reduced, typically to half its original value.

Malus's Law

Malus's Law describes how the intensity of polarized light changes as it passes through an analyzer (a second polarizer) oriented at an angle relative to the first polarizer. Specifically, the transmitted intensity is given by I = I0 cos²?, where I0 is the incident polarized light intensity and ? is the angle between the light’s polarization direction and the axis of the analyzer.

Light Intensity

Light intensity is a measure of the energy carried by light per unit area per unit time, typically expressed in watts per square meter (W/m²). It quantifies how much power is delivered by the light to a surface, and changes in intensity are important in analyzing the performance of optical systems involving polarizers and analyzers.
