Use the data in Table 3.2 to sketch a graph showing the radial wave function for a hydrogen 2 s

Use the data in Table 3.2 to sketch a graph showing the...

Key Concepts

Hydrogen Atom Orbitals

Hydrogen atom orbitals are solutions to the Schrödinger equation for the simplest atomic system. Each orbital is characterized by quantum numbers that define its energy, shape, and orientation. The 2s orbital, for example, belongs to the second energy level and exhibits unique radial characteristics like the presence of a node and an exponential decay at large radii.

Graphical Representation in Quantum Mechanics

Graphing the radial wave function provides a visual interpretation of how electron probability amplitudes vary with distance from the nucleus. Such representations help to identify key features like maxima, minima, and nodes, and illustrate the behavior of the wave function as it approaches the nucleus and as it decays at larger distances, thereby enhancing understanding of atomic structure.

Radial Wave Function

The radial wave function describes how the amplitude of an electron’s wave function varies as a function of distance from the nucleus. It is derived from solving the radial part of the Schrödinger equation in spherical coordinates and captures important features such as peaks, troughs, and nodes that indicate regions of high and low electron probability density.

Nodes

Nodes are specific points where the radial wave function crosses zero, meaning the probability density of finding an electron at those distances is zero. In the context of hydrogen 2s orbitals, the presence of a radial node is significant because it indicates a change in sign of the wave function and reflects the quantum mechanical behavior of electrons in different energy states.

Transcript

00:01 All right.

00:02 In this question, we're using the radial part of a wave function for the 2s atomic orbital in order to draw a graph of that value.

00:15 So it tells us to look at table 3 .2 in the textbook, and they show that the radial part of the wave function is equal to.

00:24 So this was radial part of the ray function as a function of r, which is the radius.

00:29 And this is equal to 1 over 2 times the square root of 2 times 2 minus r times e to the negative r over 2.

00:43 All right.

00:44 And really just like whenever you're graphing anything like this, you should look at what the major player in the function is.

00:51 The major player is that e value because everything else is just kind of like a slope intercept form.

00:56 If this wasn't here, this would just be a straight line.

00:59 Right.

00:59 This is a, a constant and then you got minus r so this will be your y intercept and then your slope right but with that e function we know that a negative e value will be this kind of a shaped graph and then it just comes to a matter of finding that y intercept if you have to graph it by hand and then finding a zero if there happens to be one in this case i just took this graph and i threw it into an online grapher and brought the picture in here to analyze.

01:30 So we can see the y intercept occurs right here.

01:33 And that's not necessarily important because remember our radius is what we're basing it off of.

01:40 And we can't have a negative radius.

01:42 That doesn't make sense.

01:43 So really our nucleus is right here.

01:45 This is our nucleus.

01:46 I'll put n for nucleus.

01:47 And then this is really showing us kind of the radial part of this distribution, right? and so this is over here.

01:58 And then notice that right here, this is really the interesting part of this whole graph.

02:02 Remember, this is for the 2s orbital...
