Using the information provided in Fig. 40 , determine the...

Using the information provided in Fig. 40 , determine the total resistance of a $2-\mathrm{cm}$ length of the material having a perpendicular surface area of $1 \mathrm{~cm}^{2}$ at a temperature of $0^{\circ} \mathrm{C}$. Note the vertical log scale.

Key Concepts

Resistivity

Resistivity is an intrinsic property of a material that quantifies how strongly it opposes the flow of electric current. It is independent of the shape or size of the material and is typically represented by the symbol ?. This property is essential for determining the resistance of a given sample using the relationship between resistivity and geometry, especially when the material's temperature and other environmental conditions are specified.

Electrical Resistance Calculation

Electrical resistance is the measure of a material's opposition to the flow of electric current and is calculated by combining the material's resistivity with its physical dimensions. For a uniform material, the resistance (R) of a segment can be determined using the formula R = ?L/A, where L is the length of the material and A is its cross-sectional area. This relationship means that for a given resistivity, longer lengths result in higher resistance, while larger cross-sectional areas reduce resistance.

Logarithmic Scale Interpretation

Interpreting a graph with a logarithmic scale is crucial when data spans several orders of magnitude. A vertical log scale compresses the scale so that exponential differences in the measured values are represented linearly, allowing for easier comparison and analysis of data trends. Understanding how to read such a graph is important for accurately determining values like resistivity from experimental data, which can then be used in resistance calculations.

Temperature Dependence of Resistivity

The resistivity of materials often varies with temperature, meaning that a material's resistance at a certain temperature, like 0°C in this problem, may differ significantly from its resistance at other temperatures. This dependency is usually depicted in graphs where temperature is a variable, and accurate interpretation requires careful attention to the conditions under which the resistivity data were obtained.
