Using the Laplace transform and showing the details, find the current $t(\theta)$ in the circuit in $\mathrm{Fg}, 127,$ assuming $i(0)=0$ and: $$\begin{array}{l} R=25 \Omega, L=0.1 \mathrm{H}, v=490 \mathrm{e}^{-54} \mathrm{V} \text { if } \\ 0 < t < 1 \text { and } 0 \text { if } t > 1 \end{array}$$

Using the Laplace transform and showing the details, find the current $t(\theta)$ in the circuit in $\mathrm{Fg}, 127,$ assuming $i(0)=0$ and:
$$\begin{array}{l}
R=25 \Omega, L=0.1 \mathrm{H}, v=490 \mathrm{e}^{-54} \mathrm{V} \text { if } \\
0 < t < 1 \text { and } 0 \text { if } t > 1
\end{array}$$

Key Concepts

Piecewise Input Functions and Step Functions

Many practical circuits are driven by inputs that change over time, often modeled as piecewise functions. Using step functions (Heaviside functions) in the Laplace domain allows these inputs to be expressed compactly, facilitating the application of the Laplace transform to systems with time-varying sources.

Transfer Function and Impedance Modeling

Analyzing circuits in the Laplace domain involves representing circuit components by their impedances (for example, representing resistors with R and inductors with sL). The transfer function, which is derived from these impedance representations, relates the output (such as current or voltage) to the input, and is essential for understanding the system dynamics.

Inverse Laplace Transform and Partial Fraction Decomposition

Once the circuit equations are solved in the s-domain, the inverse Laplace transform is used to convert the solution back to the time domain. Techniques like partial fraction decomposition are typically employed to break down complex algebraic expressions into simpler terms for which the inverse transforms are readily known.

Laplace Transform in Circuit Analysis

The Laplace transform converts differential equations governing circuit behavior into algebraic equations in the s-domain. This transformation simplifies the analysis of circuits, especially when dealing with linear systems containing reactive components, by allowing manipulations of algebraic expressions instead of differential equations.

Handling Initial Conditions

In circuit problems, initial conditions such as initial currents or voltages are crucial, as they influence the system's response. The Laplace transform naturally incorporates these conditions into the algebraic equations, ensuring that the complete system response, including its transient behavior, is accurately calculated.
