Using the tables for water, determine the specific entropy...

Using the tables for water, determine the specific entropy at the indicated states, in $\mathrm{kJ} / \mathrm{kg} \cdot \mathrm{K}$. Check the results using $I T$. In each case, locate the state by hand on a sketch of the $T-s$ diagram. (a) $p=5.0 \mathrm{MPa}, T=400^{\circ} \mathrm{C}$ (b) $p=5.0 \mathrm{MPa}, T=100^{\circ} \mathrm{C}$ (c) $p=5.0 \mathrm{MPa}, u=1872.5 \mathrm{~kJ} / \mathrm{kg}$ (d) $p=50 \mathrm{MPa}_{\text {t saturated vanor }}$

Using the tables for water, determine the specific entropy at the indicated states, in $\mathrm{kJ} / \mathrm{kg} \cdot \mathrm{K}$. Check the results using $I T$. In each case, locate the state by hand on a sketch of the $T-s$ diagram.
(a) $p=5.0 \mathrm{MPa}, T=400^{\circ} \mathrm{C}$
(b) $p=5.0 \mathrm{MPa}, T=100^{\circ} \mathrm{C}$
(c) $p=5.0 \mathrm{MPa}, u=1872.5 \mathrm{~kJ} / \mathrm{kg}$
(d) $p=50 \mathrm{MPa}_{\text {t saturated vanor }}$

Key Concepts

Interpolation in Thermodynamic Tables

Interpolation is a mathematical technique used to estimate property values that fall between the tabulated data in thermodynamic reference tables. When the exact state does not match an entry, interpolation provides a means to approximate properties like entropy or internal energy accurately. This is crucial for detailed engineering analyses where precise values are necessary for the design and optimization of thermodynamic systems.

T-s Diagrams

A Temperature-Entropy (T-s) diagram is a graphical representation of the thermodynamic states of a substance. It is used to visualize the changes in state and the processes occurring within a system. By plotting specific points corresponding to the given states—using temperature and entropy data—the T-s diagram helps in understanding phase transitions and the efficiency of thermodynamic cycles, as well as in verifying the consistency of data obtained from tables.

Water Property Tables

Water property tables provide thermodynamic data for water and steam, including parameters like temperature, pressure, enthalpy, entropy, and specific volume. These tables are essential references in thermodynamics, enabling engineers to determine state properties for water under various conditions and identify phase changes such as boiling or condensation. They serve as the basis for analyzing and designing systems involving water and steam, like power plants and heating systems.

Thermodynamic State Determination

Determining the state of a substance involves identifying its thermodynamic properties, such as pressure, temperature, internal energy, or entropy, and then matching these conditions to the appropriate entries in the property tables. This process allows one to specify whether the state is subcooled, saturated, or superheated, which is crucial for understanding the behavior and phase of the substance in engineering applications.
