Water at 20^∘ C flows through a long elliptical duct 30 cm...

Water at $20^{\circ} \mathrm{C}$ flows through a long elliptical duct $30 \mathrm{cm}$ wide and $22 \mathrm{cm}$ high. What average velocity, in $\mathrm{m} / \mathrm{s}$, would cause the weight flow to be 500 lbf/s?

Key Concepts

Continuity Equation

The continuity equation states that for incompressible flow, the product of the cross-sectional area and the fluid velocity remains constant along a streamline. This principle is used to relate flow rates to average velocities in ducts or pipes.

Elliptical Cross-sectional Area

The calculation of the cross-sectional area for an ellipse is performed using the formula A = ?ab, where a and b are the semi-major and semi-minor axes. This concept is crucial when determining the effective area through which a fluid flows in channels with elliptical shapes.

Unit Conversion from Weight Flow to Mass Flow

In fluid dynamics, weight flow rate (a measure of force per unit time) can be converted to mass flow rate by dividing by the acceleration due to gravity. This conversion is essential when linking force-based measurements to mass and volumetric flow metrics.

Average Velocity

Average velocity is a measure of the speed at which fluid moves through a given cross-sectional area. It is derived by dividing the volumetric flow rate by the cross-sectional area, thereby connecting the mass or weight flow rate with the geometry of the duct.

Fluid Density

Fluid density, which relates mass to volume, is a vital concept in connecting mass flow rate to volumetric flow rate. Knowing the density allows one to convert between mass flow and volume flow, both of which are needed when determining the average velocity for a given flow condition.
