We make a Si bar with a p-type doping of $2 \times 10^{16} \mathrm{~cm}^{-3}$ on the left half and a p-type doping of $10^{18} \mathrm{~cm}^{-3}$ on the right side. Sketch the equilibrium band diagram, with precise values marked off, far from the doping transition at $600 \mathrm{~K}$ when the intrinsic carrier concentration is $10^{16} \mathrm{~cm}^{-3} .$ (Note: This is p type on both sides. Such a junction is known as a high-low junction rather than a $\mathrm{p}-\mathrm{n}$ junction. Observe that the doping level is comparable to $n_{i}$ on the left side! Do not worry about the exact details right near the doping transition!)

Key Concepts

Equilibrium Band Diagram

An equilibrium band diagram represents the energy levels in a semiconductor at thermal equilibrium. It shows the conduction band, valence band, and the Fermi level, illustrating how these bands are positioned and how they bend spatially due to variations in doping or material properties. This diagram is essential for understanding carrier distribution and the potential barriers within semiconductor devices.

Doping in Semiconductors

Doping involves intentionally introducing impurities into a semiconductor to change its electrical properties by altering the concentration of majority carriers. In p-type doping, acceptors are added to create more holes as majority carriers. The level of doping influences the position of the Fermi level and can modify the band structure, which is critical for device operation.

Intrinsic Carrier Concentration

Intrinsic carrier concentration is the number of electron-hole pairs generated in a pure semiconductor without any doping. It serves as a reference level when comparing doped conditions. Its value relative to the doping concentration determines the semiconductor behavior, especially when the doping level is near or below this intrinsic level.

High-Low Junction

A high-low junction refers to a junction between regions of the same conductivity type (e.g., both p-type) but with different doping concentrations. This mismatch causes band bending and a shift in the Fermi level between the two regions, leading to built-in potential differences that affect carrier movement and device properties.

Fermi Level and Band Bending

The Fermi level is the chemical potential for electrons and represents the energy level at which the probability of occupation is 50%. Variations in doping concentrations cause the Fermi level to shift relative to the band edges, and the resulting band bending at a junction indicates how the electrostatic potential varies within the material, which is crucial for understanding charge carrier dynamics in equilibrium.
